General Electric Ge PQM-T20-C-A Power Quality Meter

Send Inquiry

Request To Call Back

General Electric Ge PQM-T20-C-A Power Quality Meter

Get a Price/Quote

General Electric Ge PQM-T20-C-A Power Quality Meter Specification

Features
Harmonic analysis, waveform capture, event recording, alarm outputs

Way
Three Phase / Three or Four Wire

Protection Level
Front: IP54

Cabinet Material
Engineered Polycarbonate

Thickness
Approx. 80 mm (Panel Depth)

Rated Current
1A/5A AC

Rated Operation Voltage
Up to 600 V AC

Cooling System
Natural Air Cooling

Rated Insulation Voltage
2 kV

Components
Digital Meter Body, Detachable Display, Terminal Blocks

Cover Material
Polycarbonate/ABS

Panel Type
Flush Mount

Operating Voltage
90264 V AC/DC

Connectivity Type
RS485 (Modbus RTU), Ethernet (Optional)

Current Rating
Max 5 A (CT Secondary)

Protection Class
Class I

Control System
Microprocessor-Based

Base Material
Polycarbonate

Product Type
Power Quality Meter

Material
Industrial-grade Plastic and Metal Components

Surface Finish
Matte Finish

Standard
IEC 62053, EN 50160, IEC 61000

Surface Color
Black/Gray

Rated Voltage
100600 V AC

Frequency (MHz)
50/60 Hz (Nominal), Not MHz

Maximum Output Current
5 A (secondary circuit), 1 A (optional)

Dimension (L*W*H)
96 96 80 mm (Panel Mount)

Application
Industrial, Utility, Commercial Electrical Systems

IP Rating
IP54 (Front Panel)

Display Type
LCD (Backlit)

Waveform Snapshots
Available for disturbance capture

Energy Measurements
Import, Export, Total and Partial Energy KWh/kVARh

Current Measurement Range
0.005 6 A (via CTs)

Operating Temperature
-10C to +60C

Relative Humidity
5% to 95% (Non-condensing)

Weight
Approx. 0.7 kg

Accuracy Class
Class 0.2S, 0.5S for Energy

Alarm Outputs
2 programmable relays

Event Log/Recording
Up to 2048 events

Total Harmonic Distortion
THD up to 31st harmonic

Storage Temperature
-20C to +70C

Auxiliary Supply
88-265V AC/DC (Universal)

Power Measurements
Active, Reactive, Apparent Power

Mounting
Panel Mount (Square Cutout)

Voltage Measurement Range
10 - 600 V AC (Phase-to-Phase/Phase-to-Neutral)

Clock/Memory
Real-time clock with battery backup, on-board memory

About General Electric Ge PQM-T20-C-A Power Quality Meter

Discover a trending masterpiece for your industrial, utility, or commercial electrical systemsthe General Electric GE PQM-T20-C-A Power Quality Meter. Now available on sale, this superb device ensures enlightened energy management, delivering Class 0.2S/0.5S accuracy. Access advanced harmonic analysis, event recording, and waveform capture, supported by a brilliant LCD display and real-time data logging. With robust IP54 protection, universal auxiliary supply, and versatile mounting, this meter is engineered for reliability and longevity. Experience top-rated functionality and comprehensive power insights to elevate your power quality standards.

Versatile Application and Operation

Direction of use for the GE PQM-T20-C-A Power Quality Meter is straightforward: mount the panel in a suitable square cutout for industrial, plant, or general-purpose electrical systems, then connect inputs as per system requirements. This device is designed for both specific and broad applications, efficiently showcasing energy, voltage, and current values. Its comprehensive functionality caters to plants, factories, and commercial installations, providing operational clarity for system optimization and precision monitoring of power parameters.

Certifications and Quick Dispatch

The GE PQM-T20-C-A Power Quality Meter is certified under IEC 62053, EN 50160, and IEC 61000 standards, ensuring compliance and reliability for your facilities. With its recent arrival in the main domestic market of India, the product is ready for quick dispatch from trusted suppliers and traders. Samples are available upon request, allowing for evaluation before bulk procurement. Benefit from assured quality and efficient delivery, making your installation process seamless and trouble-free.

FAQs of General Electric Ge PQM-T20-C-A Power Quality Meter:

Q: How is the GE PQM-T20-C-A Power Quality Meter typically used in industrial applications?

A: This power quality meter is commonly installed in panel boards for monitoring and analyzing power parametersincluding voltage, current, energy, and harmonicsin industrial, utility, and commercial electrical systems.

Q: What benefits does the event recording and waveform capture feature offer?

A: The event recording and waveform snapshot features help capture and log disturbances or anomalies in electrical networks, enabling rapid diagnosis, corrective action, and improved system reliability.

Q: Where should the PQM-T20-C-A be installed for optimal usage?

A: For optimal performance, install the device in a flush-mounted panel within your main distribution panel or electrical room, ensuring panel cutout dimensions of 96 96 mm and front-panel access for monitoring.

Q: What is the process for setting alarm outputs on the meter?

A: Alarm outputs are programmable via the LCD interface or remotely through Modbus RTU or optional Ethernet connectivity. Users can set specific thresholds for voltage, current, harmonics, and events, activating relays as needed.

Q: Which standards and certifications does the meter adhere to?

A: The meter is certified under IEC 62053, EN 50160, and IEC 61000 standards, confirming its accuracy, safety, and suitability for integration into critical electrical systems.
