GE Multilin UR 8NH CT/VT Module

Get a Price/Quote

GE Multilin UR 8NH CT/VT Module Specification

Rated Operation Voltage
250V AC

Connectivity Type
Edge Card Connector, Plug-in to chassis

Protection Class
Internal electrical protection to relay standards

Rated Insulation Voltage
2kV AC (Impulse)

Cooling System
Passive

Features
Hot swappable, Field replaceable, High accuracy CT/VT input processing, Compatible with all UR series relays

Operating Voltage
110250V AC/DC

Panel Type
Plug-In Module

Protection Level
Internal Functional Protection

Components
SMD/Through-Hole Resistors, Capacitors, Transformers

Control System
Relay Protection & Automation

Rated Current
5A (CT), 1A (VT)

Cover Material
High Impact Plastic

Current Rating
5A

Way
Module (Not Applicable)

Thickness
Standard Module

Base Material
PCB Substrate

Product Type
CT/VT Module

Material
Industrial Grade PCB, Electronic Components

Surface Finish
Soldered, Laminated

Standard
GE Multilin Universal Relays (UR) Series

Surface Color
Green/Gray

Rated Voltage
250V AC/DC

Frequency (MHz)
50/60 Hz

Maximum Output Current
5A @ 60Hz

Dimension (L*W*H)
130mm x 30mm x 150mm (Approx.)

Application
Protection & Measurement interface (for UR relays)

IP Rating
Internal equipment module (No direct IP rating)

Display Type
No Display

Storage Temperature Range
-40C to +85C

Module Model
8NH

Designed For
GE Multilin UR Series Universal Relay Platform

Operating Temperature Range
-20C to +60C

Input Channels
Up to 8 CT & VT Channels

Mounting Type
Plug-In Mount

Withstand Voltage
2.5 kV RMS for 1 min

Accuracy Class
Protection and Metering Class (IEC/ANSI compliance)

Weight
Approx. 400g

GE Multilin UR 8NH CT/VT Module About

Experience splendid reliability with the GE Multilin UR 8NH CT/VT Module an affordable, classic solution for protection and metering in industrial environments. Decorated with advanced industrial-grade components and a high-impact plastic cover, this module ensures exceptional accuracy in both CT and VT input processing. Engineered for seamless plug-in mounting and a wide operating temperature range, its perfectly suited for GE Multilin UR Universal Relay Platforms. Procure this price-cut gem to enhance your industrial automation and relay protection systems with unmatched quality and efficiency.

Versatile Usage in Power and Industrial Plants

The GE Multilin UR 8NH CT/VT Module is specifically designed for accurate current and voltage input processing in power plants, substations, and heavy industrial settings. Its primary application is to support protection and measurement interfaces within GE Multilin UR relay systems. Easy to install with plug-in mounting, this module streamlines plant automation and measurement, making it indispensable for engineers and plant operators looking for a reliable, general-purpose solution tailored for both specific and broad power system use.

Sample Policy & Payment Terms for Quality Procurement

Premium samples of the GE Multilin UR 8NH CT/VT Module are available for evaluation before final procurement. We provide clear sample policies and flexible payment terms to facilitate a smooth buying process. Transportation and handling of samples incur minimal expenditure, allowing buyers to experience the modules excellence firsthand. This commitment to convenience and transparency ensures that suppliers and traders in India can make informed purchase decisions with complete confidence in product quality and reliability.

FAQs of GE Multilin UR 8NH CT/VT Module:

Q: How does the GE Multilin UR 8NH CT/VT Module enhance protection and metering functions?

A: The module integrates high accuracy CT and VT input processing, designed to ensure compliance with both IEC and ANSI protection and metering standards. This delivers reliable and precise measurements essential for relay system safety.

Q: What are the applications of this module in industrial or plant settings?

A: It is primarily used in power plants, substations, and other industrial installations, where it supports protection and measurement of electrical parameters as part of the GE Multilin UR Universal Relay Platform.

Q: When can I expect samples after requesting for procurement?

A: Samples are dispatched promptly upon request, subject to supplier availability. Exact timelines depend on stock status and transportation logistics, which are efficiently managed to minimize waiting periods.

Q: Where can this module be installed within an electrical system?

A: This plug-in module is intended for installation within the chassis of GE Multilin UR series relay panels, allowing easy integration into control and protection systems.

Q: What is the process for replacing or upgrading this module on-site?

A: The module is hot swappable and field replaceable, allowing for safe and straightforward upgrades or replacements without disrupting relay or panel operations. Simply remove the old unit and insert the new module using the edge card connector.

Q: What benefits do buyers receive when selecting this product from a supplier or trader in India?

A: Buyers in India enjoy competitive pricing, assurance of industrial-grade quality, prompt sample availability, and flexible payment options. This makes the procurement process straightforward and cost effective.
