GE MULTILIN D60N03HKHF8LH6DM6UP67UXXW67 LINE DISTANCE PROTACTION RELAY

Send Inquiry

Request To Call Back

GE MULTILIN D60N03HKHF8LH6DM6UP67UXXW67 LINE DISTANCE PROTACTION RELAY

Get a Price/Quote

MOQ : 1 Piece

GE MULTILIN D60N03HKHF8LH6DM6UP67UXXW67 LINE DISTANCE PROTACTION RELAY Specification

Control System
Digital - Microprocessor Based

Cabinet Material
Steel

Connectivity Type
Ethernet, RS232, RS485

Cooling System
Natural Cooling

Rated Current
1A or 5A (Selectable)

Cover Material
Sheet Metal

Thickness
185 mm (approx)

Rated Insulation Voltage
2kV RMS (1 min)

Features
Multi-zone protection, Fault location, Event recording, Programmable logic, IEC61850 Protocol

Protection Level
Comprehensive line distance, phase, and ground fault

Panel Type
Front Mount/Flush Mount

Way
Rack Mount (4U High, 1/2 Rack Width)

Operating Voltage
110V/220V AC/DC

Current Rating
1A / 5A CT Input

Base Material
Reinforced Plastic

Rated Operation Voltage
110-250V AC/DC

Components
Microprocessor, Display, Protection Relays, Communication Ports

Protection Class
Class 1

Product Type
Line Distance Protection Relay

Material
Industrial Grade Plastic, Metal Front Panel

Surface Finish
Matte

Standard
IEC 60255, ANSI C37

Surface Color
Grey and Black

Rated Voltage
48-250V DC / 110-240V AC

Frequency (MHz)
50/60 Hz

Maximum Output Current
5A

Dimension (L*W*H)
192mm (H) x 445mm (W) x 185mm (D)

Application
High Voltage Protection, Distance Protection for Transmission Lines

IP Rating
Ip54

Display Type
LCD Alphanumeric Display

About GE MULTILIN D60N03HKHF8LH6DM6UP67UXXW67 LINE DISTANCE PROTACTION RELAY

The featured GE MULTILIN D60N03HKHF8LH6DM6UP67UXXW67 Line Distance Protection Relay stands as an acclaimed and pivotal solution in high voltage protection. Distinguished by its advanced microprocessor-based control system and multi-protocol communication ports, this ineffable device ensures comprehensive, reliable protection for transmission line applications. Get enhanced performance with settings secured by password, robust event and fault recording, and broad compatibility with IEC61850, DNP3.0, and more. Its rugged buildreinforced plastic base, metal front, matte finish, and IP54 ratingunderscores industrial prowess. Ideal for traders, suppliers, and exporters across India.

Versatile Applications and User Spectrum

The GE MULTILIN D60N03HKHF8LH6DM6UP67UXXW67 is designed for high-voltage protection scenarios, making it ideal for transmission line distance protection in power utilities, industrial sectors, and grid operations. Frequently used by electrical engineers, utility operators, and energy infrastructure specialists, its specific use covers fault location, event recording, and comprehensive protection. Still, its general use expands into any critical environment requiring advanced, digital relay-based security for uninterrupted power delivery.

Certifications, Availability, and Domestic Market Reach

Acclaimed for conforming to IEC 60255 and ANSI C37 standards, the relays certifications assure compliance and quality. Samples can be shipped to customers for pre-purchase evaluation with reputable transport services, ensuring timely delivery. Given its applicability, the relay features a competitive list price suitable for Indias expansive domestic market, catering to suppliers and end-users needing reliable, state-of-the-art protection solutions.

FAQs of GE MULTILIN D60N03HKHF8LH6DM6UP67UXXW67 LINE DISTANCE PROTACTION RELAY:

Q: How does the GE D60N03HK relay enhance transmission line protection?

A: The relay uses microprocessor-based digital control and multi-zone protection features to provide fast and accurate isolation of faults, ensuring reliable operation of transmission lines.

Q: What protocols are supported by this distance protection relay?

A: It supports a wide range of industry-standard protocols, including IEC61850, DNP3.0, Modbus, IEEE C37.118, and IEC 60870-5-103 for seamless system integration.

Q: Where can this relay be typically installed?

A: Ideal for panel or rack mounting, it is commonly installed in utility substations, power plants, and industrial electrical control rooms requiring advanced distance protection.

Q: When is the recommended time to set up event and fault recording?

A: Event and fault recording settings should be configured during initial commissioning to ensure all system operations and disturbances are accurately documented from the start.

Q: What is the process for adjusting relay settings securely?

A: Settings can be adjusted through a password-protected front panel or via PC software, ensuring only authorized personnel can modify system parameters.
