Genius Bus Controller

Get a Price/Quote

Genius Bus Controller Specification

Protection Class
Class II

Rated Current
10A

Current Rating
10A

Rated Insulation Voltage
500V

Way
Multi-way

Operating Voltage
24V DC

Features
Overload Protection, Modular Design, Surge Protection

Rated Operation Voltage
24V DC

Control System
Bus Communication Protocol

Cabinet Material
ABS Plastic

Connectivity Type
RS485, CAN Bus

Panel Type
DIN Rail Mount

Base Material
ABS Plastic

Protection Level
IP20

Components
Microcontroller, Communication Chips, Power Module

Cooling System
Natural Air Convection

Cover Material
Polycarbonate

Thickness
45 mm

Product Type
Bus Controller

Material
Industrial Grade Electronic Components

Surface Finish
Powder Coated

Standard
IEC 61131-3

Surface Color
Grey

Rated Voltage
24V DC

Frequency (MHz)
50/60 Hz

Maximum Output Current
10A

Dimension (L*W*H)
220 mm x 120 mm x 45 mm

Application
Industrial Automation, Building Management

IP Rating
IP20

Display Type
LED Indicators

Supported Protocols
Modbus, CANopen

Operating Temperature Range
-20C to +55C

Mounting Method
DIN Rail

Communication Baud Rate
Up to 1 Mbps

Power Consumption
<12W

Expansion Capability
Supports up to 32 nodes

Humidity Range
10% to 95%, non-condensing

Response Time
<5 ms

Storage Temperature Range
-40C to +70C

About Genius Bus Controller

GE FANUC GENIUSIC660TBA101L

Text-to-speech function is limited to 200 characters

Options : History : Feedback : Donate

Reliable DIN Rail Mounting for Industrial Use

The Genius Bus Controller is purpose-built for quick DIN rail installation, making it ideal for industrial panels and control cabinets. Its compact dimensions (220 mm x 120 mm x 45 mm) allow for efficient space utilization, while the IP20 protection ensures safe operation in demanding environments typical of manufacturing and automation sectors.

Versatile Communication and Protocol Support

Supporting both Modbus and CANopen, the controller accommodates a variety of industrial automation configurations. With connectivity via RS485 and CAN Bus, and a baud rate up to 1 Mbps, integration into new or existing systems is simple, enabling swift data transfer and reliable multi-device operation up to 32 nodes.

Optimized Safety and Longevity

Constructed from industrial-grade electronic components, ABS plastic, and polycarbonate, the device offers exceptional durability. Key features like overload and surge protection, as well as Class II insulation, safeguard both the equipment and operators, ensuring long-term, worry-free operation.

FAQs of Genius Bus Controller:

Q: How is the Genius Bus Controller mounted in an industrial setup?

A: The Genius Bus Controller is designed for DIN rail mounting, which allows for secure and straightforward installation inside control cabinets and industrial panels.

Q: What protocols can the Genius Bus Controller communicate with?

A: It supports both Modbus and CANopen protocols, enabling it to interface seamlessly with a broad range of industrial automation and building management systems.

Q: When should I use expansion capabilities, and how many nodes are supported?

A: Expansion is recommended when your application requires multiple devices in a networked configuration. The controller supports up to 32 nodes via its modular design, enhancing scalability for complex installations.

Q: Where can the controller be safely operated and stored?

A: The device operates safely within an ambient temperature range of -20C to +55C and can be stored from -40C to +70C. Ideal conditions include humidity between 10% and 95% (non-condensing), common in industrial environments.

Q: What processes are protected by the Genius Bus Controllers safety features?

A: Critical processes benefit from built-in overload and surge protection, safeguarding the controller and connected devices from unexpected power anomalies and ensuring stable operation.

Q: How does the device indicate operational status or issues?

A: LED indicators on the panel provide clear visual feedback on the controllers status, offering at-a-glance monitoring and facilitating easy troubleshooting.

Q: What benefits does the modular design offer industrial users?

A: The modular design enables flexible system expansion, streamlined maintenance, and straightforward integration, ultimately reducing downtime and supporting evolving automation requirements.
