EMERSON OUTPUT MODULE KJ3001X1-BG1

Get a Price/Quote

EMERSON OUTPUT MODULE KJ3001X1-BG1 Specification

Connectivity Type
Fieldbus, Terminal Block

IP Rating
IP20

Mounting Type
Rack or Cabinet Mount

Frequency
47-63 Hz

Current
400 mA max (backplane) / 30 mA max (field) per channel

Output
24 VDC, 16 Channels

Protection Level
Isolation between channels and fieldbus

Usage & Applications
Process automation, industrial control systems

Features
Hot-swappable, supports diagnostics, LED indications for status

Installation Type
DIN Rail Mount, Cabinet Installation

Product Type
Output Module

Operating Temperature
-40C to 70C

Working Temperature
-40C to 70C

Application
Emerson DeltaV and Ovation systems, industrial automation

Supply Voltage
18-32 VDC

Accuracy
High reliability/output integrity

Dimension (L*W*H)
100 mm x 130 mm x 40 mm (Approx)

Weight
Approx. 200 g

Hot Swap Capability
Yes (can be replaced under power)

Response Time
1 ms typical

Isolation
Channel-to-bus isolation of 1500 V RMS

Humidity
5% to 95% non-condensing

Material
High-grade industrial plastic and metal casing

Approval/Certification
CE, CSA, ATEX certified for use in hazardous areas

Protocol
DeltaV Series 2 compatible

Channels
16 output channels

LED Indicators
Per channel and module status

Configuration
Configurable via DeltaV system software

Storage Temperature
-40C to +85C

Module Part Number
KJ3001X1-BG1

About EMERSON OUTPUT MODULE KJ3001X1-BG1

Take advantage of the top-rated EMERSON OUTPUT MODULE KJ3001X1-BG1celebrated for peerless reliability in industrial environments. Capitalise on its magnificent features, including sixteen output channels, channel-to-bus isolation of 1500 V RMS, and DeltaV Series 2 compatibility. It boasts hot-swap capability and rapid 1 ms response time, with robust LED indicators for optimum monitoring. CE, CSA, and ATEX certified, this module guarantees exceptional safety and output integrity. Made from high-grade materials, it offers accurate, high-quality results for Emerson DeltaV and Ovation systems.

Industries and Applications

The EMERSON OUTPUT MODULE KJ3001X1-BG1 is widely used by professional engineers and technicians in process automation fields and industrial control systems. It is suitable for use in hazardous locations, thanks to its ATEX certification. Ideal for applications in Emerson DeltaV and Ovation systems, it excels in scenarios requiring dependable output control and monitoring across manufacturing and processing industries.

Payment, Supply, and Certification

Stock is ready for fast supply, ensuring seamless procurement and minimising expenditure for industrial clients. Payment terms can be tailored to customer requirements, enhancing your purchasing experience. Certified to CE, CSA, and ATEX standards, this module exemplifies high safety and operational excellence. Sample policies are available, and rapid delivery ensures you can capitalise on process automation advancements without delay.

FAQs of EMERSON OUTPUT MODULE KJ3001X1-BG1:

Q: How does the EMERSON OUTPUT MODULE KJ3001X1-BG1 benefit process automation systems?

A: This module provides magnificent performance through its peerless reliability, rapid response time, and guaranteed isolation, making it ideal for demanding process automation environments.

Q: What certifications does the KJ3001X1-BG1 module hold for hazardous area usage?

A: It is CE, CSA, and ATEX certified, ensuring celebrated safety and suitability for usage in hazardous industrial locations.

Q: When can users take advantage of the hot swap capability of this module?

A: Users can capitalise on hot swap functionality at any time, allowing them to replace the module under power during system operation, thus avoiding downtime.

Q: Where is the EMERSON OUTPUT MODULE typically installed?

A: It is designed for DIN rail or cabinet mounting, suitable for industrial automation racks or process cabinets within factories or plant installations.

Q: What process is involved in configuring the KJ3001X1-BG1?

A: Configuration is accomplished via DeltaV system software, enabling flexible setup and diagnostics, while LED indicators offer real-time status reporting.

Q: How does the isolation feature protect the system?

A: Channel-to-bus isolation of 1500 V RMS ensures that each channel is distinctly protected, preventing interference and electrical faults between outputs and the control bus.
