ELCON 1026-A-0-0242-AA ISOLATED SIGNAL CONVERTERS

Send Inquiry

Request To Call Back

ELCON 1026-A-0-0242-AA ISOLATED SIGNAL CONVERTERS

Get a Price/Quote

MOQ : 1 Piece

ELCON 1026-A-0-0242-AA ISOLATED SIGNAL CONVERTERS Specification

Control System
Analog/Digital Control Circuits

Components
High Precision Signal Transformer, Opto Isolator

Thickness
36 mm

Cabinet Material
ABS Plastic

Rated Operation Voltage
24 V DC

Way
2 Way

Features
3 Way Galvanic Isolation, Low Power Consumption, Compact Design

Protection Class
II

Operating Voltage
18 32 V DC

Rated Current
20 mA

Base Material
ABS Plastic

Cooling System
Natural Air Cooling

Protection Level
IP20

Current Rating
020 mA, 420 mA

Cover Material
Polycarbonate

Connectivity Type
Screw Terminal

Rated Insulation Voltage
2.5 kV RMS

Panel Type
DIN Rail Mount

Product Type
Isolated Signal Converter

Material
ABS Plastic

Surface Finish
Matte

Standard
IEC 61326, EN 61010-1

Surface Color
Grey

Rated Voltage
24 V DC

Frequency (MHz)
DC to 100 Hz

Maximum Output Current
< 20 mA

Dimension (L*W*H)
102 mm x 22.5 mm x 110 mm

Application
Industrial Signal Isolation PLC/SCADA

IP Rating
IP20

Storage Temperature Range
-20C to +80C

Isolation Voltage
Up to 2.5kV RMS between Input, Output, and Power Supply

Power Consumption
1.5 W

Input Signal
0-20mA, 4-20mA, 0-10V DC selectable

Mounting
DIN Rail 35 mm

Response Time
< 50 ms

Output Signal
0-20mA, 4-20mA, 0-10V DC selectable

Operating Temperature Range
-10C to +55C

Weight
120 grams

Humidity
Up to 95% RH (Non-condensing)

About ELCON 1026-A-0-0242-AA ISOLATED SIGNAL CONVERTERS

Discover the ELCON 1026-A-0-0242-AA Isolated Signal Converterwhere unparalleled precision meets imposing reliability. Engineered for industrial excellence, this device features selectable input and output signals (020mA, 420mA, 010V DC) and unrivaled 2.5kV RMS isolation between input, output, and power. The compact, matte-finished ABS construction ensures steadfast durability. Competitive pricing is available, but act swiftlythis offer is ending soon. Select ELCON for an ineffable blend of advanced technology, rugged build, and reliable performance in demanding industrial environments.

Versatile Application Across Industrial Automation

ELCON 1026-A-0-0242-AA Isolated Signal Converters are ideal for PLC and SCADA systems, offering ineffable accuracy for analog and digital control circuits. Their robust design suits diverse site applications, from manufacturing plants to process industries. Recommended for usage in environments with demanding signal isolation needs, the converter handles media like current and voltage signals seamlessly. Apply it anywhere secure, reliable signal transmission and isolation are critical in complex industrial setups.

Swift Delivery and Comprehensive Export Market Coverage

Enjoy secure shipping and prompt delivery times on the ELCON 1026-A-0-0242-AA Isolated Signal Converter, available across Indias main domestic market and export markets alike. We provide easy exchange options and quality-checked samples to enhance your purchasing experience. Our streamlined logistics ensure timely arrivals, while attentive support guarantees peace of mind from order to installation. Whether you need a single unit or bulk supply, our delivery system stands ready to serve your business needs efficiently.

FAQs of ELCON 1026-A-0-0242-AA ISOLATED SIGNAL CONVERTERS:

Q: How do I select the appropriate input and output signal for ELCON 1026-A-0-0242-AA?

A: You can easily select between 020mA, 420mA, and 010V DC for both input and output signals, ensuring compatibility with a wide range of industrial automation systems.

Q: What are the main benefits of using this isolated signal converter in industrial applications?

A: The ELCON 1026-A-0-0242-AA offers robust 3-way galvanic isolation, compact design, low power consumption, and increased safety for analog and digital control circuits, making it ideal for PLC/SCADA signal isolation.

Q: When can I expect delivery after placing an order?

A: Delivery times are prompt and secured, with most orders shipped quickly within the main domestic and export markets. Sample availability and exchange options further expedite your experience.

Q: Where can the ELCON 1026-A-0-0242-AA be mounted for optimal use?

A: This converter is designed for DIN Rail 35 mm mounting, allowing for secure installation within industrial control panels or cabinets.

Q: What process should I follow to request a sample before purchasing in bulk?

A: Simply contact your supplier or trader to request a quality-checked sample. Our team will facilitate secure shipping and provide the necessary details for evaluation.

Q: How does the ELCON 1026-A-0-0242-AA provide protection in harsh industrial environments?

A: With its IP20 and Class II protection levels, ABS housing, and polycarbonate cover, the converter ensures durability against dust and operational stresses while maintaining signal integrity.
