Ebg Snubber Resistor Esp62/20 15Rj

Get a Price/Quote

Ebg Snubber Resistor Esp62/20 15Rj Specification

Mounting Type
Panel Mount / Chassis Mount

Operating Temperature
-55C to +155C

Connector Type
M4 Terminal

Power Factor
N/A (Resistive Component)

Efficiency
n/a (Passive Resistor)

IP Rating
IP20

Overheating Protection
Self-limiting, No active protection

Feature
Low Inductance, Pulse Absorption

Surface Finish
Insulated Epoxy

Humidity %
Max 95% RH

Insulation Material
Epoxy Resin

Shape
Rectangular

Product Type
Snubber Resistor

Application
Power Electronics, Inductive Load Protection

Protection Level
High Voltage Protection

Frequency (MHz)
50-60 Hz (rated for standard AC) / Suitable for MHz switching applications

Rated Voltage
AC 1500 V / DC 2000 V

Energy Consumption
Passive component, no energy consumption

Output Type
Resistive

Color
Silver / White

Dimension (L*W*H)
62 mm x 20 mm x 15 mm

Weight
40 g

Phase
Single Phase

Size
62 mm x 20 mm

Input Voltage
AC 1500 V / DC 2000 V

No Of Poles
2

Connection Type
Screw Terminal

Material
Ceramic/Metal Oxide

Dielectric Strength
2500 V

Temperature Coefficient
<100 ppm/C

Max Pulse Energy
8500 J

Resistance Value
15 5%

Model Number
ESP62/20 15RJ

RoHS Compliance
Yes

Max Continuous Power
20 W

Package Type
EPS Modular

About Ebg Snubber Resistor Esp62/20 15Rj

The Ebg Snubber Resistor ESP62/20 15RJ is your last chance to secure a superior snubber solution, designed for high-voltage protection in power electronics. Personalise your power setup with this potent and commanding 15 5% resistor, tailored for superior pulse absorption and low inductance. Redeem its robust capabilitydelivering 20W continuous power and withstanding up to 8500J pulse energy. Its rectangular ceramic/metal oxide body ensures durability, while the insulated epoxy finish provides safe, reliable performance. RoHS compliant, panel mountable, and ready for demanding AC or MHz switching environmentschoose excellence.

Highlighted Applications and Features of ESP62/20 15RJ

The Ebg Snubber Resistor ESP62/20 15RJ is expertly crafted for power electronics and inductive load protection, offering exceptional high-voltage safeguarding. Used extensively in snubber circuits and surge protection applications, its key features include low inductance, high pulse energy absorption, and an insulated epoxy surface finish. The resistor boasts superior dielectric strength and operates efficiently in humid conditions, making it a reliable component across a range of industrial and electronic setups. Its robust design ensures dependable long-term usage.

Payment Terms, Supply Ability & Shipping Advantages

Ebg Snubber Resistor ESP62/20 15RJ is available with flexible payment terms for hassle-free transactions. Packing & Dispatch is efficiently managed, ensuring your product is safely shipped and reaches your location intact. Express shipping options are provided for urgent requirements, with a steady supply ability to handle both large and small orders. Samples are available upon request, allowing users to assess quality before making bulk purchases. Reliable delivery systems guarantee timely arrival worldwide.

FAQs of Ebg Snubber Resistor Esp62/20 15Rj:

Q: How can I redeem a sample of the ESP62/20 15RJ snubber resistor before bulk ordering?

A: Samples of the ESP62/20 15RJ are available upon request. Contact the supplier or trader in India and specify your requirements to initiate the sample dispatch process.

Q: What are the primary benefits of using the ESP62/20 15RJ in power electronics?

A: This potent resistor provides superior high-voltage protection, low inductance, and robust pulse absorption, making it ideal for safeguarding sensitive components in demanding electronic circuits.

Q: Where can the ESP62/20 15RJ be applied most effectively?

A: The ESP62/20 15RJ is best suited for snubber circuits, inductive load protection, power electronics, and environments requiring high-voltage and high-pulse energy handling.

Q: What are the surface and mounting options for this resistor?

A: The ESP62/20 15RJ features an insulated epoxy surface finish and can be mounted securely on panels or chassis via its screw terminal (M4) connectors.

Q: How is packing & dispatch managed for ordered units?

A: Products are professionally packed for maximum protection during transit, and dispatched promptly. Express shipping is available for urgent deliveries.
