B&R X20 AO 4622 INPUT MODULE

Get a Price/Quote

B&R X20 AO 4622 INPUT MODULE Specification

Operating Voltage
24 VDC

Panel Type
DIN Rail Mountable

Components
Analog Output Circuit, Status LEDs, Terminal Blocks

Base Material
Plastic Housing

Current Rating
0.5 A

Rated Insulation Voltage
500 V (Test voltage)

Way
4 Channels

Cooling System
Passive

Connectivity Type
Removable Terminal Blocks, X20 Bus Connection

Protection Class
Class II

Features
Hot swap capable, Channel diagnostic, Short-circuit and overload protection

Cabinet Material
Plastic

Control System
B&R X20 Series Automation

Rated Operation Voltage
24 VDC

Cover Material
Plastic

Protection Level
Short-circuit proof

Rated Current
0.5 A (per channel)

Thickness
Standard Compact Modular Design

Product Type
Analog Output Module

Material
High-grade Industrial Plastic and Electronic Components

Surface Finish
Matte

Standard
IEC 61131-2

Surface Color
Black / Grey

Rated Voltage
24 VDC

Maximum Output Current
0.5 A (per channel)

Dimension (L*W*H)
99 x 24 x 74 mm

Application
Industrial Automation, Process Control, Factory Automation

IP Rating
IP20

Display Type
Status LED Indicators

Resolution
12 bit

Status Indicators
LED per Channel, Power/Status LED

Humidity
5% to 95% (non-condensing)

Output Voltage Range
0 to 10 V, 10 V

Mounting Type
DIN Rail

Weight
Approx. 120 g

Response Time
1 ms

Environmental Operating Temperature
0C to +60C

Hot Swap Capability
Yes

RoHS Compliant
Yes

Storage Temperature
-25C to +70C

Signal Type
Analog

Output Type
2 x Analog Outputs (Voltage/Current configurable)

Output Current Range
0 to 20 mA, 4 to 20 mA

B&R X20 AO 4622 INPUT MODULE About

Unlock extraordinary versatility with the B&R X20 AO 4622 Input Modulean essential piece for seamless industrial automation. This prime module delivers first-rate performance with two configurable analog outputs, supporting both voltage (0 to 10 V, 10 V) and current (0 to 20 mA, 4 to 20 mA) outputs. Highly recommended for any advanced control system, it features a rapid 1 ms response time, channel diagnostic, short-circuit and overload protection, and LED indicators. Its robust plastic housing ensures durability, while hot swap capability and DIN rail mounting facilitate swift, hassle-free installation. RoHS compliance and modular design make it a must-have for demanding applications.

Competitive Edge & Diverse Applications

The B&R X20 AO 4622 Input Module stands out with its hot-swap capability, short-circuit and overload protection, and channel diagnosticsensuring minimized downtime and optimal safety. Its extraordinary adaptability makes it a perfect choice for industrial automation, process control, and factory automation sectors. Useful in environments requiring real-time, first-rate analog signal processing, this module features robust housing and passive cooling for reliable long-term machine performance.

Worldwide Supply, Export Policies & Pricing

With stock ready for immediate shipment, the B&R X20 AO 4622 Input Module is offered to global markets at the lowest price, ensuring excellent value. OEMs and traders in India and beyond benefit from transparent sample policies and competitive asking prices. Our FOB Port is conveniently located for swift export, ensuring you can secure this must-have input module promptly for your automation needs worldwide.

FAQs of B&R X20 AO 4622 INPUT MODULE:

Q: How do you configure the output type on the B&R X20 AO 4622 Input Module?

A: You can easily configure each channel for either voltage (0 to 10 V, 10 V) or current (0 to 20 mA, 4 to 20 mA) output, providing flexible signal options for a wide range of industrial applications.

Q: What are the key benefits of using the B&R X20 AO 4622 for automation projects?

A: The module offers rapid response time, hot swap capability, short-circuit and overload protection, and clear LED status indicators, all contributing to increased reliability and minimized system downtime.

Q: When should you consider using this module in your control system?

A: It is ideal for environments requiring precise analog output, robust safety features, and seamless integration with B&R X20 Series automation systems, particularly in process or factory automation.

Q: Where can the B&R X20 AO 4622 Input Module be mounted?

A: Designed for convenient DIN rail mounting, the module fits seamlessly into both new and existing cabinet setups across industrial, process, and factory automation environments.

Q: What is the process for hot-swapping the B&R X20 AO 4622 Input Module?

A: Hot swapping is supported, allowing users to replace or install the module without powering down the system, significantly simplifying maintenance and reducing operational interruptions.

Q: How can the unit withstand diverse environmental conditions?

A: With an operating temperature range of 0C to +60C, humidity tolerance of 5% to 95% (non-condensing), and high-grade industrial plastic housing, the module remains reliable in tough industrial settings.
