B&R 7AI261.7 ANALOG INPUT MODULE AI261

Get a Price/Quote

B&R 7AI261.7 ANALOG INPUT MODULE AI261 Specification

Operating Temperature
0C to +60C

Power Supply
Supplied via POWERLINK bus

Application
Process automation, industrial control

Working Temperature
0C to +60C

Noise Level
Low

Cooling Method
Natural convection

Connector Type
Removable terminal

Features
Galvanically isolated channels, diagnostics, modular design

Current Range
4 to 20 mA, 0 to 20 mA, 0 to 10 V, 10 V (input signal ranges)

Product Type
Analog Input Module

Input Voltage
24 VDC (typical via bus)

Voltage Protection
Overvoltage and reverse polarity protection

Material
Industrial grade plastic

Storage Temperature
-25C to +70C

Weight
Approx. 140 g

Input Resolution
12 bit

Input Type
Voltage or current selectable

Channel Isolation
Yes, channel-to-bus and channel-to-channel

Update Rate
2 ms

Part Number
7AI261.7

System Compatibility
B&R X20 automation system

Module Width
37 mm

Mounting
DIN rail

Input Impedance
>100 k (voltage), <250 (current)

Number of Analog Inputs
8 channels

Diagnostic Functionality
Channel status LEDs and diagnostics registers

About B&R 7AI261.7 ANALOG INPUT MODULE AI261

Redeem cutting-edge performance for industrial automation with the trending B&R 7AI261.7 Analog Input Module AI261. Boasting a marvelous 8-channel capability and a soaring 12-bit resolution, this module features reduced noise and lustrous signal quality. Effortlessly select between voltage and current inputs, while galvanized isolation ensures elevated protectionchannel-to-bus and channel-to-channel. Diagnostics are simplified with status LEDs and registers, and robust construction stands up to challenging industrial environments. Its modular design, update rate of just 2 ms, and compatibility with B&R X20 systems make it an indispensable choice.

Versatile Applications and Operational Excellence

The B&R 7AI261.7 Analog Input Module AI261 is tailored for both specific and general industrial uses such as process automation and control. It features a modular architecture and galvanically isolated channelsensuring robust signal integrity and safety. Effortless channel selection, comprehensive diagnostics, and status LEDs streamline operation and troubleshooting. For optimal use, mount it securely on a DIN rail, connect via removable terminals, and integrate seamlessly with the B&R X20 system for optimal process reliability.

Secure Packaging and Hassle-Free Dispatch

Secure shipping and reliable packing & dispatch practices ensure your B&R 7AI261.7 module arrives safely. Each unit is meticulously boxed using industrial-grade protection. We serve the main domestic markets of India with prompt attention, and quotation requests are welcomed for bulk or dedicated orders. Flexible payment terms simplify acquisition, and our supply process is designed for speed and peace of mind, delivering quality promptly wherever your project site is located.

FAQs of B&R 7AI261.7 ANALOG INPUT MODULE AI261:

Q: How do I select between voltage and current input types on the 7AI261.7 module?

A: The module allows users to manually configure each channel for voltage or current input, making it flexible for various application requirements. Refer to the user manual for specific jumper or software settings.

Q: What are the main benefits of using the B&R 7AI261.7 Analog Input Module in industrial automation?

A: The AI261 module offers elevated channel isolation, low noise, fast 2 ms updates, and advanced diagnostics, ensuring reliable and accurate signal acquisition for optimal control and process automation.

Q: Where should the module be installed for best performance?

A: Mount the 7AI261.7 securely on a DIN rail within an appropriate enclosure to maintain its operating temperature range and protect it from environmental hazards.

Q: What protections are included with the 7AI261.7 module?

A: The module is engineered with robust overvoltage and reverse polarity protection, safeguarding it and connected devices from common wiring errors and transient faults.

Q: How does the diagnostic feature of the 7AI261.7 assist in troubleshooting?

A: It is equipped with status LEDs for each channel and diagnostics registers, enabling rapid identification of faults and simplifying maintenance activities.
