B&R 5PC820.1505-00 HMI

Get a Price/Quote

B&R 5PC820.1505-00 HMI Specification

Current Range
0.6 A

Output Current
0.6 A

Connector Type
Terminal Block, Ethernet (RJ45)

Rated Power
15 W

Cooling Method
Natural Air Cooling

Rated Current
0.6 A

Application
Industrial Automation Control Panels, Operator Terminals

Power Supply
24 V DC

Working Temperature
0C to +55C

Operating Temperature
0C to +55C

Output Type
TFT LCD Display

Features
Touch Screen Operation, High Resolution Display, Robust Housing, Ethernet Port

Power Factor
>0.9

Phase
Single Phase (DC Input)

Noise Level
<40 dB

Product Type
Human Machine Interface (HMI)

Output Power
15 W

Input Voltage
24 V DC

Voltage Protection
Overvoltage, Reverse Polarity Protection

Efficiency
>85%

Material
Plastic Housing with Aluminum Front Panel

Storage Temperature
-20C to +60C

Weight
Approx. 1.2 kg

Operating System
Proprietary/Embedded (B&R Automation Runtime)

Resolution
1024 x 768 pixels (XGA)

Color Depth
16.2 Million Colors

Communication Ports
Ethernet, USB Host/Device, Serial (RS232/RS485)

Brightness
400 cd/m²

Display Size
15 Inch TFT LCD

Mounting Type
Panel Mount

Touch Technology
Analog Resistive Touch

Backlight
LED

Front Protection
IP65 (front side only)

About B&R 5PC820.1505-00 HMI

Experience instant savings with the B&R 5PC820.1505-00 HMI, a dominant solution for industrial automation. This renowned operator terminal features a famed 15-inch TFT LCD display with 1024 x 768 XGA resolution and 16.2 million colors, delivering crisp visuals. Engineered with robust IP65 front protection and efficient analog resistive touch technology, it excels in demanding environments. Benefit from markdown pricing on every purchase while enjoying versatile connectivityEthernet, USB, Serialand outstanding efficiency (>85%). Make a smart investment in reliable control panel solutions with B&Rs expert design.

Industrial Control Made Simple

The B&R 5PC820.1505-00 HMI is designed for operator terminals and control panels in industrial automation. Its touch screen operation streamlines interaction for plant floor personnel, making data input and monitoring more efficient. Commercial users employ this device in manufacturing, processing, and logistics environments, benefiting from a user-friendly interface and robust build. Directions for use include panel mounting and connection to Ethernet or serial ports for seamless communication across hardware systems.

Supply, Sample Policy, and Domestic Market Reach

Buyers can place a purchase order for the B&R 5PC820.1505-00 HMI with reliable supply ability. Our main domestic market covers diverse industries across the region, and sample policies are available on request. We encourage customers to estimate project requirements and discuss sample options before finalizing their bulk order, ensuring tailored solutions for automation needs. Fast procurement and efficient supply channels support your domestic installations.

FAQs of B&R 5PC820.1505-00 HMI:

Q: How does the B&R 5PC820.1505-00 HMI benefit industrial automation operations?

A: The B&R 5PC820.1505-00 HMI enhances industrial automation by providing a high-resolution touch screen interface, robust housing, and reliable connectivity, significantly improving control and monitoring efficiency in diverse manufacturing environments.

Q: What are the main communication ports available on the B&R 5PC820.1505-00 HMI?

A: This HMI offers Ethernet, USB Host/Device, and Serial (RS232/RS485) ports, allowing seamless integration with industrial networks and equipment for optimal data exchange and system control.

Q: When is the ideal time to consider upgrading to the B&R 5PC820.1505-00 HMI?

A: Upgrading to this HMI is ideal when your current operator terminals require better resolution, advanced touch functionality, or more robust environmental protection and connectivity in demanding industrial settings.

Q: Where should the B&R 5PC820.1505-00 HMI be installed within an automation setup?

A: The HMI is intended for panel mounting in control panels or operator stations, offering premium front-side IP65 protection and a compact design suitable for various industrial locations.

Q: What process should buyers follow for sample policy or bulk purchase orders?

A: Interested buyers should request a sample policy review, then estimate their order quantities and submit a purchase order for supply. Discussions can tailor solutions to specific industrial requirements and domestic market needs.

Q: How is the B&R 5PC820.1505-00 HMI used in commercial automation environments?

A: Commercial users deploy this HMI for expedited data entry, real-time process monitoring, and system management in environments such as manufacturing lines, storage logistics, and production facilities.
