BOSCH 041359-206401 CNC SYSTEM PCB CARD

Get a Price/Quote

BOSCH 041359-206401 CNC SYSTEM PCB CARD Specification

Operating Voltage
24V DC

Base Material
FR4 Epoxy

Control System
Bosch CNC Controller Compatible

Protection Class
Class II

Connectivity Type
Edge Connector

Current Rating
2A

Rated Insulation Voltage
250V AC

Rated Current
2A

Features
High Reliability, Industrial Quality, Easy Installation

Rated Operation Voltage
24V DC

Components
Integrated Circuits, Capacitors, Resistors, Connectors

Cover Material
PCB Mask

Protection Level
Conformal Coated

Thickness
1.6 mm

Cooling System
Passive Cooling

Way
Multilayer

Panel Type
Single Panel

Product Type
CNC System PCB Card

Material
FR4 Epoxy Glass Fiber

Surface Finish
HASL (Hot Air Solder Leveling)

Standard
Industrial Grade

Surface Color
Green

Rated Voltage
24V DC

Frequency (MHz)
50/60 Hz

Maximum Output Current
2A

Dimension (L*W*H)
340 mm x 200 mm x 20 mm

Application
Bosch CNC Machines

IP Rating
IP20

Compatibility
Bosch CNC Automation Systems

Replacement Type
OEM/Original

PCB Layers
4-Layer Internal Routing

Input Type
Edge Connector

Insulation Resistance
>100 M

Weight
Approx. 420 g

Part Number
041359-206401

Humidity Tolerance
5% to 85% RH

Mounting Type
Rack Mountable

Operating Temperature Range
0C to +60C

RoHS Compliance
Yes

Signal Type
Analog and Digital

Storage Temperature Range
-20C to +70C

About BOSCH 041359-206401 CNC SYSTEM PCB CARD

Experience an unprecedented bargain with the BOSCH 041359-206401 CNC SYSTEM PCB CARD, now available at a reduced price during our exclusive promotion. This immaculate card is engineered for Bosch CNC Automation Systems, bringing breathtaking performance through its high reliability and industrial-grade standards. Featuring a rack-mountable design, multilayer FR4 epoxy construction, and robust signal support for analog and digital inputs, it excels in demanding environments. Benefit from OEM/original replacement quality, seamless edge connector integration, and RoHS compliance, making it a superior and cost-effective solution for your automation needs.

Extra Features & Versatile Application

The BOSCH 041359-206401 CNC SYSTEM PCB CARD offers multilayer routing, conformal coating, and a single-panel design for enhanced durability. With integrated circuits, capacitors, and resistors, it ensures high reliability and precise analog/digital signal handling. Ideal for Bosch CNC Machines, it excels in industrial automation tasks, supporting easy installation and passive cooling for superior operational stability across diverse manufacturing environments.

Certifications, Supply Ability & Payment Terms

Certified to RoHS standards and rated IP20/Class II, the BOSCH 041359-206401 CNC SYSTEM PCB CARD guarantees exceptional safety and quality. Orders are processed by purchase order, with secure packaging ensuring product integrity during transportation. Our supplier and trader network maintains robust supply ability, enabling prompt delivery worldwide. Flexible payment terms are available to streamline procurement and meet your business requirements efficiently.

FAQs of BOSCH 041359-206401 CNC SYSTEM PCB CARD:

Q: How is the BOSCH 041359-206401 CNC SYSTEM PCB CARD installed in CNC machines?

A: The card is designed for rack-mountable integration using an edge connector, facilitating quick and secure installation within Bosch CNC Automation Systems.

Q: What is the advantage of the PCB cards multilayer FR4 epoxy construction?

A: Its 4-layer FR4 epoxy construction offers unmatched durability, enhanced insulation resistance, and stable performance in industrial settings.

Q: When should this CNC PCB card be replaced in automation systems?

A: It is recommended to replace the PCB card when experiencing signal processing issues or during routine maintenance to ensure uninterrupted system reliability.
