BAUMULLER CIRCUIT BOARD 3.9823C

Get a Price/Quote

BAUMULLER CIRCUIT BOARD 3.9823C Specification

Connectivity Type
Edge Connector / Plug-in Header

Protection Class
Class II

Operating Voltage
24V DC

Rated Insulation Voltage
500V AC

Features
High reliability, robust design, plug-in replaceable

Thickness
1.6 mm

Control System
Baumuller Drive & Control

Panel Type
Single panel module

Rated Operation Voltage
24V DC

Current Rating
3A

Cover Material
Solder Resist Coating

Protection Level
IP20

Components
Integrated Circuits, Passive and Active Components

Base Material
Epoxy Glass Fiber (FR4)

Cooling System
Convection (None)

Rated Current
3A

Way
2 Layer PCB

Product Type
Baumuller Circuit Board

Material
High-quality FR4 Epoxy Glass

Surface Finish
HASL (Hot Air Solder Leveling)

Standard
OEM (Original Equipment Manufacturer)

Surface Color
Green

Rated Voltage
24V DC

Frequency (MHz)
Up to 10 MHz

Maximum Output Current
3A

Dimension (L*W*H)
160 mm x 100 mm x 18 mm

Application
Industrial Automation / Motor Control

IP Rating
IP20

Mounting Type
Plug-in/Slot Mount

Life Expectancy
> 100,000 hrs at rated conditions

Manufacturing Technology
Wave Soldered

Weight
Approx. 0.22 kg

Signal Type
Analog/Digital Supported

Compliance
RoHS Compliant

PCB Code
3.9823C

Temperature Range
0°C to +60°C

About BAUMULLER CIRCUIT BOARD 3.9823C

Highlighted for its phenomenal performance and reliability, the BAUMULLER CIRCUIT BOARD 3.9823C is expertly engineered for industrial automation and motor control. Utilise our exclusive Discount Offer to acquire this polished and lustrous plug-in/slot mount module. Crafted from high-quality FR4 Epoxy Glass and coated with solder resist, it delivers robust IP20 protection and sustains a life expectancy exceeding 100,000 hours at rated conditions. RoHS compliant and OEM standard, this two-layer PCB supports analog/digital signals up to 10MHz, offering impeccable integration for modern plant systems. Dont miss this opportunity to enhance your automation setup with outstanding circuit technology!

Application Excellence in Industrial Settings

The BAUMULLER CIRCUIT BOARD 3.9823C is widely utilised in industrial automation and sophisticated motor control systems. With its robust plug-in replaceable design, it stands out in high-demand plant applications, ensuring consistent performance under varying operational circumstances. Integrated circuits along with passive and active components allow seamless compatibility with Baumuller Drive & Control systems. Additional features such as high reliability and a wave-soldered assembly underline its suitability for continuous, mission-critical industrial processes.

Certifications, Sample Policy, and Market Outreach

BAUMULLER CIRCUIT BOARD 3.9823C is RoHS compliant, ensuring adherence to prominent manufacturing standards. Our sample policy allows for minimal outlay prior to larger handover, specifically tailored for the main domestic market of India. We guarantee the lowest price for OEM-standard products and offer accessible support for traders and suppliers nationwide. Experience confidence in procurement with certified product reliability and comprehensive customer service throughout the transaction process.

FAQs of BAUMULLER CIRCUIT BOARD 3.9823C:

Q: How does the BAUMULLER CIRCUIT BOARD 3.9823C benefit industrial applications?

A: This circuit board is engineered for demanding industrial automation and motor control, providing high reliability, long life expectancy, and seamless integration with Baumuller Drive & Control systems.

Q: What manufacturing technology is used for this circuit board?

A: The BAUMULLER CIRCUIT BOARD 3.9823C is produced using advanced wave soldering technology for polished, durable assembly and optimal electrical performance.

Q: Where can this circuit board be used, and for which plant applications is it suitable?

A: It is ideal for use in industrial plants, specifically for automation and motor control processes requiring reliable analog and digital signal support.
