ALLEN BRADLY 1756-IF16HK ANALOG INPUT MODULE

Send Inquiry

Request To Call Back

ALLEN BRADLY 1756-IF16HK ANALOG INPUT MODULE

Get a Price/Quote

MOQ : 1 Piece

ALLEN BRADLY 1756-IF16HK ANALOG INPUT MODULE Specification

Cabinet Material
Industrial Plastic

Protection Level
Conformal coated for harsh environments

Way
16 Channels

Rated Operation Voltage
30 V DC

Operating Voltage
10-30 V DC

Rated Insulation Voltage
250V AC

Rated Current
N/A (Input Module)

Thickness
Standard (as per module)

Connectivity Type
Backplane (ControlLogix Chassis)

Base Material
Industrial Grade Plastic

Cooling System
Chassis-based, Natural Airflow

Panel Type
Module Type

Cover Material
Polycarbonate

Features
High-density analog input, conformal coating, harsh environment support

Current Rating
N/A (Input Module)

Control System
Rockwell ControlLogix

Protection Class
Class I

Components
Input Terminals, Status LEDs, Conformal Coating

Product Type
Analog Input Module

Material
Plastic and Metal

Surface Finish
Matte

Standard
Allen Bradley Factory Standard

Surface Color
Grey

Rated Voltage
30 V DC (max)

Frequency (MHz)
N/A (Analog Input)

Maximum Output Current
N/A (Input Module)

Dimension (L*W*H)
145 mm x 35 mm x 145 mm (approx.)

Application
Industrial Automation Control Systems

IP Rating
IP20

Display Type
Status LED Indicators

Resolution
16 Bits

Storage Temperature Range
-40C to +85C

Input Signal Range
4-20 mA, 0-20 mA

Diagnostics
Enhanced, Channel-level

Module Type
Conformal Coated (Harsh Environment Kit)

Mounting Type
Chassis Mount (ControlLogix)

Backplane Current (24V DC)
50 mA

Input Type
Differential Analog Current Input

Channel Status Indication
Individual LED for Each Channel

Humidity
5% to 95% non-condensing

Operating Temperature Range
-25C to +70C

Backplane Current (5.1V DC)
160 mA

Isolation Voltage
Basic Insulation, 250V (continuous)

Wire Size
14-22 AWG

About ALLEN BRADLY 1756-IF16HK ANALOG INPUT MODULE

Elevate your automation system with the monumental ALLEN BRADLY 1756-IF16HK Analog Input Module, featuring pristine performance and ultimate reliability. Designed for demanding environments, its differential analog current input supports signal ranges of 4-20 mA and 0-20 mA, ensuring high-precision data acquisition at a remarkable 16-bit resolution. Industry professionals favor its robust conformal coating, individual channel LED indicators, and enhanced diagnostics. Add to Cart today to secure a special rate and join those leaving favorable reviews for superior industrial automation solutions.

Advantages and Applications of ALLEN BRADLY 1756-IF16HK Analog Input Module

The ALLEN BRADLY 1756-IF16HK offers competitive advantages like enhanced channel-level diagnostics, robust insulation, and resilience in harsh conditions due to conformal coating. Primarily used in industrial automation control systems, its high-density input channels are ideal for process control, making it a top choice for precise monitoring in general and specific applications. Dependable mounting and status LED indicators further elevate its utility.

Supply Capability, Certifications, and Sample Availability

We ensure consistent supply ability for the ALLEN BRADLY 1756-IF16HK Analog Input Module, with prompt quotation and transport services for orders in India. Certified to Allen Bradley Factory Standard, each module is rigorously tested for quality assurance. Samples are available upon request and can be shipped efficiently to facilitate seamless evaluation, making procurement and integration both convenient and reliable.

FAQs of ALLEN BRADLY 1756-IF16HK ANALOG INPUT MODULE:

Q: How does the ALLEN BRADLY 1756-IF16HK module enhance system reliability in harsh environments?

A: Its conformal coating provides substantial protection against moisture and contaminants, allowing the module to operate reliably even in challenging industrial settings.

Q: What type of input signals does the 1756-IF16HK support?

A: The module accepts differential analog current inputs with ranges of 4-20 mA and 0-20 mA, optimized for precise data acquisition in automation systems.

Q: When should I use the 1756-IF16HK module in my control system?

A: It is ideal when high-density, channel-level diagnostics and individual LED indicators are required for monitoring analog input in industrial automation environments.

Q: Where can buyers get a quotation and sample of the 1756-IF16HK module?

A: Quotations and sample requests can be processed through authorized suppliers and traders in India, who also provide transport services for delivery.

Q: What is the typical usage process for installing the 1756-IF16HK Analog Input Module?

A: The module is designed for chassis mounting in Rockwell ControlLogix systems. Simply connect appropriate wire sizes to input terminals, secure in position, and verify via LED status indicators.

Q: What benefits do the enhanced diagnostics and channel-level status indicators provide?

A: Enhanced diagnostics and channel LEDs enable quick troubleshooting and real-time monitoring, ensuring efficient system operation and minimized downtime.
