ALLEN BRADLY 1756-EN2T COMMUNICATIONS MODULE

Get a Price/Quote

MOQ : 1 Piece

ALLEN BRADLY 1756-EN2T COMMUNICATIONS MODULE Specification

Operating Temperature
0C to 60C (32F to 140F)

Cooling Method
Convection

Application
Industrial Ethernet/IP network communication for ControlLogix systems

Features
Bridge communication, supports TCP/IP and EtherNet/IP, up to 100 EtherNet/IP nodes

Working Temperature
0C to 60C (32F to 140F)

Connector Type
RJ45 for Ethernet

Power Supply
Supplied by ControlLogix backplane (75 mA @ 5.1 VDC, 55 mA @ 24 VDC)

Product Type
Communication Module

Input Voltage
N/A (Powered from ControlLogix chassis)

Material
Plastic housing

Storage Temperature
-40C to 85C (-40F to 185F)

Weight
0.35 kg (0.77 lbs)

Backplane Current Draw
75 mA @ 5.1V DC, 55 mA @ 24V DC

Communication Ports
1 Ethernet port

Maximum Network Data Rate
10/100 Mbps auto-negotiation

Configuration
RSLogix 5000 or Studio 5000 Logix Designer software

Catalog Number
1756-EN2T

Relative Humidity
5% to 95% noncondensing

Shock
30 g

Mounting
Chassis-mounted

Vibration
2 g @ 10 to 500 Hz

Installation Category
IEC 60664-1, Pollution Degree 2

Chassis Compatibility
ControlLogix

Network Protocols
EtherNet/IP, TCP/IP, HTTP, SNMP, CIP

Enclosure Type Rating
IP20

Firmware Upgradeable
Yes

Dimensions (HxWxD)
145 mm x 35 mm x 140 mm (5.71 in x 1.38 in x 5.51 in)

Module Location
Any slot in ControlLogix chassis

Redundancy Support
Yes, when used with redundant chassis and power supplies

Status Indicators
Module status, network activity, link status

ALLEN BRADLY 1756-EN2T COMMUNICATIONS MODULE About

Gain exclusive access to first-class industrial connectivity with the ALLEN BRADLEY 1756-EN2T Communications Module. Esteemed for its eminent performance, this in-demand module features a single Ethernet port supporting EtherNet/IP, TCP/IP, HTTP, SNMP, and CIP protocols. Experience enlightened control via bridge communication for up to 100 EtherNet/IP nodes, seamless integration with ControlLogix chassis, and outstanding reliability, even in challenging environments. Enjoy IP20 protection, robust construction, redundancy support, and an enlightened user interface-all handpicked for superior network communication.

Diverse Industrial Utilization

The ALLEN BRADLEY 1756-EN2T COMMUNICATIONS MODULE finds application across various industrial domains such as manufacturing plants, automation centers, and energy management sites. Its flexibility makes it suitable for integration by engineers, system designers, and maintenance professionals requiring robust Ethernet/IP communication within ControlLogix architectures. From assembly lines to process control, the module empowers users with reliable data exchange for critical and scalable automation projects.

Export Excellence and Supply Capability

ALLEN BRADLEY 1756-EN2T modules are eminently transported to key international markets, ensuring timely exchange and deployment. Each module is carefully handed over following rigorous quality checks. With robust supply ability, we ensure consistent availability for our industrial clients. Sample units can be shipped upon request to facilitate informed purchasing decisions and seamless integration with existing infrastructure. Our commitment is to provide first-rate modules, globally and efficiently.

FAQ's of ALLEN BRADLY 1756-EN2T COMMUNICATIONS MODULE:

Q: How does the 1756-EN2T module benefit an industrial Ethernet/IP network?

A: The 1756-EN2T module provides fast and reliable Ethernet/IP communication, supporting up to 100 EtherNet/IP nodes and vital protocols. This facilitates seamless data exchange and scalable integration for industrial automation applications.

Q: What is the installation process for the ALLEN BRADLEY 1756-EN2T Communications Module?

A: The module can be installed in any slot within a ControlLogix chassis. Configuration is performed using RSLogix 5000 or Studio 5000 Logix Designer software, and it is powered directly from the chassis backplane for simplified setup.

Q: Where can the 1756-EN2T module be used?

A: This module is suited for industrial sites requiring Ethernet/IP network communication, such as manufacturing facilities, power plants, and process automation environments.

Q: When is it advantageous to use the redundancy support feature of this module?

A: Redundancy support becomes valuable when high system availability is essential, such as in mission-critical control or safety applications, ensuring minimal downtime in the event of hardware failures.

Q: What are the primary usage environments considered for the 1756-EN2T module?

A: The module is designed for environments with operating temperatures from 0C to 60C, and can withstand vibration, shock, and varying humidity, making it ideal for demanding industrial applications.

Q: How does firmware upgradeability enhance the module's lifecycle?

A: Firmware upgradeability allows users to keep the module updated with the latest features and security improvements, extending its operational lifespan and compatibility with evolving network standards.
