ALLEN BRADLEY SERVO DRIVE 2094-BM01-S

Get a Price/Quote

ALLEN BRADLEY SERVO DRIVE 2094-BM01-S Specification

Output Current
2.8 A

Features
Compact design, High precision control, Fast response, Integrated safety functions

Connector Type
Plug-in terminal connections

Phase
Three Phase

Power Factor
>0.98

Rated Current
2.8 A

Operating Temperature
0°C to +55°C

Current Range
2.8-3.1 A

Power Supply
AC Supply

Output Type
Three-Phase

Working Temperature
0°C to +55°C

Noise Level
<65 dB

Cooling Method
Forced Air Cooling

Rated Power
1.3 kW

Application
Industrial Automation, Motion Control

Product Type
Servo Drive

Output Power
1.3 kW

Output Frequency
0-400 Hz

Input Voltage
360-480 V AC

Voltage Protection
Overvoltage and undervoltage protection

Efficiency
Typically >95%

Material
Industrial Grade Components

Line Regulation
±1%

Storage Temperature
-40°C to +85°C

Weight
Approx. 5.5 kg

Communication Interface
SERCOS interface, Ethernet/IP (optional)

Protection Class
IP20

Model Number
2094-BM01-S

Overload Capacity
150% for 60 seconds

Relative Humidity
5-95% non-condensing

Standards Compliance
EN 61800-5-1, EN 61800-3

Regenerative Capability
Yes

Response Time
<1 ms

Series
Kinetix 6000

Isolation
Galvanic isolation between control and power circuits

Firmware Upgrade
Field-upgradable

Mounting Type
Panel Mount

Minimum Load
No minimum load required

Maximum Altitude
2000 m without derating

Control Mode
Position, Velocity, and Torque Control

Dimensions
Approx. 380 x 110 x 195 mm

Display
Status LEDs

ALLEN BRADLEY SERVO DRIVE 2094-BM01-S About

Experience the triumphant performance of the ALLEN BRADLEY SERVO DRIVE 2094-BM01-S, a popular choice in industrial automation. Utilise offer-driven advantages with its resplendent, compact design and immaculate output power of 1.3 kW. Personalise your motion control with position, velocity, and torque control modes and benefit from exceptional precision, fast response (<1 ms), and field-upgradable firmware. Engineered for reliability, this drive features integrated safety, robust IP20 protection, and galvanic isolation. Ideal for demanding environments, its compliant with global standards and tailored for panel mounting. Discover advanced efficiency with Allen Bradleywhere innovation meets control excellence.

Versatile Features and Efficient Use

The ALLEN BRADLEY SERVO DRIVE 2094-BM01-S distinguishes itself with high precision control, regenerative capability, and status LEDs for swift monitoring. It is specifically designed for industrial automation and motion control, excelling in general and specialized use. Simply panel mount the unit, connect via SERCOS or Ethernet/IP interface, and enjoy seamless integration into your system. Its compact dimensions and forced air cooling promote reliable, continuous operation, even under demanding scenarios, supporting your most challenging automation goals.

Payment Terms, Certifications, and Delivery

Benefit from secure shipping and reliable delivery across the domestic market. The ALLEN BRADLEY SERVO DRIVE 2094-BM01-S is compliant with EN 61800-5-1 and EN 61800-3 certification standards, ensuring top performance and safety. Delivered promptly to your facility, we offer flexible payment terms to suit diverse trading preferences. Trust our streamlined process for a seamless purchasing experienceget your drive delivered efficiently and ready for integration in your industrial environment.

FAQs of ALLEN BRADLEY SERVO DRIVE 2094-BM01-S:

Q: How does the ALLEN BRADLEY SERVO DRIVE 2094-BM01-S enhance motion control in industrial automation?

A: This servo drive delivers high precision control with fast response times, offering position, velocity, and torque control modes for superior adaptability within industrial motion applications.

Q: What interfaces are available for communication with this servo drive?

A: The drive supports SERCOS interface natively, and offers Ethernet/IP connectivity as an optional upgrade, enabling flexible system integration.

Q: When can I expect delivery after placing an order for the 2094-BM01-S in India?

A: Secure shipping is provided, and your servo drive is delivered promptly across the domestic market, generally within an agreed timeframe based on order confirmation and stock availability.

Q: Where should the ALLEN BRADLEY 2094-BM01-S be installed for optimal performance?

A: This servo drive is designed for panel mounting, ensuring efficient cooling and reliable operation in industrial environments.

Q: What certifications ensure the quality and compliance of the 2094-BM01-S?

A: The drive is certified according to EN 61800-5-1 and EN 61800-3 standards, guaranteeing compliance with international safety and electromagnetic compatibility requirements.

Q: How do I utilise the drives regenerative capability?

A: The 2094-BM01-S is equipped for energy regeneration, enabling efficient recapture of kinetic energy during deceleration and enhancing overall energy efficiency in automation processes.
