ALLEN BRADLEY OUTPUT MODULE 1746-OW8 A

Get a Price/Quote

ALLEN BRADLEY OUTPUT MODULE 1746-OW8 A Specification

Cabinet Material
Module casing of industrial plastic

Control System
SLC 500 PLC System Compatible

Operating Voltage
24-240V AC / 24-125V DC

Rated Operation Voltage
24-240V AC, 24-125V DC

Cover Material
Transparent Polycarbonate (for terminal cover)

Panel Type
DIN Rail Mount

Connectivity Type
Screw Terminal Block

Protection Class
Class I

Protection Level
IP20

Rated Insulation Voltage
250V AC

Components
Electromechanical Relays, Terminal Blocks

Base Material
High Durability Engineering Plastic

Way
8 Point (8 Channels)

Cooling System
Passive Air

Thickness
Standard Module Thickness (Approx. 35 mm)

Current Rating
2A / point

Rated Current
2A per channel max.

Features
Hot-swappable; Channel Status LEDs; High Isolation

Product Type
Relay Output Module

Material
Industrial Grade Plastic with Electronic Components

Surface Finish
Matte Finish

Standard
IEC 61131; UL 508; CE marked

Surface Color
Grey

Rated Voltage
24-240V AC / 24-125V DC

Frequency (MHz)
47-63 Hz (for AC)

Maximum Output Current
2A per point, 8A per module

Dimension (L*W*H)
151 x 35 x 145 mm approx.

Application
PLC Automation Panels; Industrial Controls

IP Rating
IP20

Display Type
Status LEDs for Channel Indication

Response Time
10ms ON, 10ms OFF max.

Isolation Voltage (Input to Output)
1500V AC, 1 min

Module Type
Sourcing/Sinking Relay Output

Weight
Approx. 300g

Storage Temperature Range
-40C to 85C

Mounting Type
DIN Rail or Panel Mount

Operating Temperature Range
0C to 60C

About ALLEN BRADLEY OUTPUT MODULE 1746-OW8 A

Get the illustrious ALLEN BRADLEY OUTPUT MODULE 1746-OW8 A for your industrial automation needs. This first-string output module supports 8-point (channel) relay outputs with a remarkable operating temperature range of 0C to 60C. Crafted from high-durability industrial grade plastic and featuring a matte grey finish, it meets IEC 61131, UL 508, and CE standards. Explore instant checkout for your sourcing/sinking relay output requirements. The module provides high isolation (1500V AC), status LEDs, and hot-swappable capabilityperfect for modern PLC automation panels.

Competitive Edge & Core Applications

The ALLEN BRADLEY OUTPUT MODULE 1746-OW8 A brings competitive advantages like hot-swappability, channel status LEDs, and robust isolation voltage. Its premium design and first-string compliance with international standards ensure enduring performance in harsh industrial conditions. Highly suitable for PLC automation panels and industrial control systems, this module excels in environments that demand reliability and seamless integration with SLC 500 PLC systems.

Supply Ability & Timely Delivery Assurance

With efficient logistics and supply capability, ALLEN BRADLEY OUTPUT MODULE 1746-OW8 A is readily available for rapid order completion. Sample units may be provided upon request to qualified buyers. Our streamlined delivery processes ensure prompt dispatch, minimizing downtime and guaranteeing that your projects stay on schedule. Experience swift procurement and reliable shipment, backed by a supply chain tuned for industrial demands.

FAQs of ALLEN BRADLEY OUTPUT MODULE 1746-OW8 A:

Q: How does the ALLEN BRADLEY OUTPUT MODULE 1746-OW8 A benefit industrial automation systems?

A: This module enhances automation efficiency with reliable relay outputs, hot-swappable installation, and clear channel indication through status LEDs, making it ideal for demanding industrial control environments.

Q: What mounting options are available for the 1746-OW8 A module?

A: The output module supports both DIN rail and panel mount installations, offering flexibility for various cabinet and panel configurations.

Q: When can I expect delivery after placing an order for the 1746-OW8 A?

A: Delivery times are expedited through robust logistics and can be confirmed during order completion. In-stock units are typically dispatched shortly after order confirmation.

Q: Where can this output module be used?

A: It is designed for PLC automation panels and a wide range of industrial control systems, specifically within SLC 500 PLC-compatible setups.

Q: What is the process for requesting a sample unit?

A: To request a sample, contact the supplier or trader with your requirements. Qualifying buyers may receive samples based on availability and specific procurement criteria.

Q: How does the 1746-OW8 A ensure operational safety and reliability?

A: The module features high isolation voltage, robust insulation, status-indicating LEDs, and industrial-grade materials, all contributing to secure and reliable long-term operation.
