ALLEN BRADLEY OUTPUT MODULE 1734-VHSC24

Get a Price/Quote

ALLEN BRADLEY OUTPUT MODULE 1734-VHSC24 Specification

Power Supply
24V DC via POINT I/O Bus

Phase
Single Phase (signal level inputs)

Current Range
Nominal input current <100 mA

Noise Level
N/A (Silent operation)

Cooling Method
Natural convection

Features
4 differential or 8 single-ended input channels, high-speed counter up to 1 MHz, configuration via RSLogix 5000, diagnostic LEDs, removal and insertion under power (RIUP)

Working Temperature
-20C to +55C

Operating Temperature
-20C to +55C

Output Current
50 mA (per channel maximum)

Rated Power
N/A (I/O module)

Output Type
High-Speed Counter Output

Connector Type
POINT I/O Removable Terminal Block (RTB), 8 pole

Application
Distributed I/O, high-speed counting, position, length or speed monitoring

Product Type
Output Module

Output Power
N/A (Module - not power supply)

Input Voltage
24V DC

Voltage Protection
Overvoltage protection integrated

Efficiency
N/A (Not applicable for this device type)

Material
Industrial-grade Plastic

Line Regulation
N/A (not specified)

Storage Temperature
-40C to +85C

Weight
Approx. 35 g

Counter Modes Supported
Up, Down, Quadrature, Pulse-Direction, Frequency Measurement

Module Status Indicators
Green/Red (module status), Yellow (per channel input status)

Dimensions (W x H x D)
12 x 120 x 75.5 mm

Catalog Number
1734-VHSC24

Communication Protocol
POINT I/O

Number of Inputs
4 differential or 8 single-ended

Mounting Type
DIN Rail Mount

Max Input Frequency
1 MHz

Series
POINT I/O 1734 Series

Isolation Voltage
50V (continuous, Basic Insulation) between field-side and logic-side

Wire Size Supported
0.251.5 mm (2416 AWG)

About ALLEN BRADLEY OUTPUT MODULE 1734-VHSC24

Redeem unprecedented performance by choosing the ALLEN BRADLEY OUTPUT MODULE 1734-VHSC24, the first-string module from the renowned POINT I/O 1734 Series. Remarked for its versatility, this module offers 4 differential or 8 single-ended inputs with precision of the finest orderhandling frequencies up to 1 MHz. Pick yours for reliable up, down, quadrature, or pulse-direction counter modes. With robust DIN rail mounting, integrated overvoltage protection, and diagnostic LEDs, grab assurance in distributed I/O, high-speed counting, and industrial measurement where every detail counts.

Versatile Applications Across Industries

The ALLEN BRADLEY OUTPUT MODULE 1734-VHSC24 serves as a premier choice for applications that demand high-speed counting and precise movement monitoring. Its widely used for position, speed, and length measurement in industries such as packaging, material handling, conveyor automation, and robotics. Its reliable performance makes it useful across manufacturing plants, automotive assembly lines, and system integration projects, ensuring stable operation in demanding environments where accuracy and rapid response are essential.

Payment Terms and Supply Details

With a market value reflecting its industrial-grade standard, the ALLEN BRADLEY OUTPUT MODULE 1734-VHSC24 is available with favorable payment terms. Packaging is handled with care to ensure safe packing & dispatch across India. Samples may be available for qualifying businesses seeking to verify authenticity or compatibility. The supply ability is strong, with streamlined distribution channels ensuring prompt deliveries to meet your operational schedules without delays, supporting your automation and inventory requirements efficiently.

FAQs of ALLEN BRADLEY OUTPUT MODULE 1734-VHSC24:

Q: How do I configure the ALLEN BRADLEY 1734-VHSC24 Output Module for my application?

A: Configuration can be performed using RSLogix 5000 software, allowing you to set input channels, counter modes, and diagnostic features to suit specific high-speed counting tasks.

Q: What are the main usage benefits of this output module?

A: The module provides real-time monitoring of position, length, and speed, supports multiple counter modes, and is equipped with diagnostic LEDs for simplified troubleshooting and maintenance in industrial automation settings.

Q: Where is the ALLEN BRADLEY 1734-VHSC24 typically used?

A: This module is extensively used in applications like packaging, material handling, robotics, and conveyor systems across manufacturing and processing industries.

Q: When should I use differential versus single-ended inputs?

A: Use differential inputs when higher noise immunity and signal integrity are critical, such as in electrically noisy environments. Single-ended inputs are suitable for shorter, simpler wiring runs.

Q: What process is involved in installing the 1734-VHSC24 module?

A: Mount the module onto the DIN rail, connect the removable terminal block for wiring, supply 24V DC through the POINT I/O bus, and finalize configuration through RSLogix 5000 before commissioning the system.
