ALLEN-BRADLEY MPL-B4530F-MJ72AA SERVO MOTOR

Send Inquiry

Request To Call Back

ALLEN-BRADLEY MPL-B4530F-MJ72AA SERVO MOTOR

Get a Price/Quote

MOQ : 1 Piece

ALLEN-BRADLEY MPL-B4530F-MJ72AA SERVO MOTOR Specification

Way
3-phase

Rated Insulation Voltage
600V

Base Material
Steel

Cooling System
Natural convection

Protection Level
IP65

Protection Class
Class F

Features
Compact frame, high torque output, absolute feedback encoder, robust housing

Current Rating
Continuous: 31.2A, Peak: 41.2A

Thickness
110 mm housing body

Connectivity Type
Standard power and encoder connectors

Rated Operation Voltage
230-400V AC

Components
Integrated feedback encoder, connection terminals

Cover Material
Aluminium

Operating Voltage
400V AC

Control System
Digital servo control

Rated Current
31.2A

Product Type
Servo Motor

Material
Industrial-grade alloy steel

Surface Finish
Matte

Standard
IEC 60034 and UL Listed

Surface Color
Black

Rated Voltage
400V AC

Frequency (MHz)
50/60Hz

Maximum Output Current
41.2A

Dimension (L*W*H)
Approx. 445mm x 195mm x 170mm

Application
Precision motion control, robotic arms, CNC machinery

IP Rating
IP65

Max Power Output
7.0 kW

Shaft Diameter
32 mm

Insulation System
Class F (155C)

Mounting Type
Flange

Bearing Life
20,000 Hours

Rotational Inertia
0.019 kgm

Environmental Conditions
0C to +40C, humidity 90% RH (non-condensing)

Weight
Approx. 18 kg

Model Number
MPL-B4530F-MJ72AA

Frame Size
453 mm

Feedback Type
Multi-turn Absolute Encoder (MJ72AA)

Safety Standards
EN 61800-5-1

Rated Speed
3000 RPM

Peak Torque
33.2 Nm

About ALLEN-BRADLEY MPL-B4530F-MJ72AA SERVO MOTOR

Discover preeminent performance at an unbeatable price with the ALLEN-BRADLEY MPL-B4530F-MJ72AA Servo Motor, now available for a limited time on clearance. This elite, industrial-grade servo motor is engineered with exquisite precision for demanding applications such as robotic arms and CNC machinery. Boasting a robust 33.2 Nm peak torque, 7.0 kW max output, and Class F insulation, it ensures peak reliability under rigorous conditions (0C to +40C, 90% RH). Designed with a 32 mm shaft, flange mounting, and IP65-rated housing, this advanced solution meets IEC 60034 and UL standards for trusted, long-lasting integration.

Versatile Application and Usage

The ALLEN-BRADLEY MPL-B4530F-MJ72AA SERVO MOTOR excels in demanding precision motion control applications, including robotic arms and CNC machinery. It is ideally used across industries requiring elite performance, such as manufacturing automation, robotics, and machine tools. This servo motor is frequently deployed as a critical component in processes necessitating rapid, accurate positioning, making it suitable both for specific and general use across varied environments demanding high-torque, reliable operation.

Secure Packaging and Certifications

Our secure shipping process ensures your Allen-Bradley MPL-B4530F-MJ72AA SERVO MOTOR arrives safely, ready for immediate installation. Every shipment is meticulously packaged for maximum protection against transit damage. Serving the main domestic market in India, we guarantee compliance with international quality standards, including EN 61800-5-1 and UL. All items are certified and include proper documentation, so customers can trust in both the safety and the quality of their purchase.

FAQs of ALLEN-BRADLEY MPL-B4530F-MJ72AA SERVO MOTOR:

Q: How is the ALLEN-BRADLEY MPL-B4530F-MJ72AA servo motor typically used?

A: This servo motor is primarily used for precision motion control in applications like robotic arms, CNC machinery, and automated manufacturing systems, where high torque and accurate position feedback are essential.

Q: What benefits does the integrated multi-turn absolute encoder provide?

A: The integrated multi-turn absolute encoder (MJ72AA) allows precise position detection, ensuring fast setup, accurate motion control, and reliable performance in repetitive or complex automation tasks.

Q: Where can the MPL-B4530F-MJ72AA servo motor be installed?

A: Owing to its robust IP65 rating and wide environmental tolerance (0C to +40C, 90% RH), this motor can be installed in both standard and challenging industrial environments, including humid or dusty settings.

Q: What is the process for ordering and receiving this servo motor in India?

A: Orders are processed through authorized suppliers and traders. Each motor is securely packaged and shipped, with careful handling to ensure safe arrival at your specified location anywhere in India.

Q: What certifications does the MPL-B4530F-MJ72AA motor hold, and why are they important?

A: The motor is certified to international standards including EN 61800-5-1, IEC 60034, and is UL Listed. These certifications ensure that the product meets rigorous safety, quality, and performance benchmarks vital for industrial use.
