ABB PCB CARD 3BSE022458R1

Get a Price/Quote

ABB PCB CARD 3BSE022458R1 Specification

Operating Voltage
24V DC

Features
High Reliability, Precision Manufacturing, Easy Rack Mount, OEM Replacement

Connectivity Type
Edge Connector/ Backplane Interface

Base Material
Fiberglass Reinforced Epoxy

Panel Type
Mounting on System Rack

Rated Operation Voltage
24V DC

Rated Insulation Voltage
500V AC

Cooling System
Passive Cooling

Current Rating
2A

Components
ICs, Connectors, SMD, Passive Components

Protection Level
Standard Industrial IP20

Cabinet Material
N/A (PCB only)

Cover Material
None (Open PCB)

Protection Class
Class I

Control System
Compatible with ABB DCS/PLC Systems

Thickness
1.6 mm

Rated Current
2A

Way
Multi-layer

Product Type
PCB Card / Module

Material
FR4 (Fiberglass) and High-Quality Epoxy Resin

Surface Finish
HASL (Hot Air Solder Leveling)

Standard
ABB OEM Quality

Surface Color
Green

Rated Voltage
24V DC

Frequency (MHz)
50/60 Hz

Maximum Output Current
2A

Dimension (L*W*H)
185 mm x 80 mm x 18 mm

Application
ABB Process Automation Systems

IP Rating
IP20

Life Span
Designed for > 10 years under industrial use

Mounting Method
Plug-in PCB for ABB Control Systems

Storage Temperature Range
-40°C to +85°C

Repairability
Serviceable by ABB Authorized Centers

Weight
Approx. 180 grams

Operating Temperature Range
0°C to +60°C

Compliance Certifications
RoHS, CE

Compatible Systems
ABB AC 800M, S800 I/O, and related automation platforms

PCB Layers
Multilayer (typically 4-6 layers)

Model Number
3BSE022458R1

Environmental Resistance
Conformal Coating Against Moisture and Dust

About ABB PCB CARD 3BSE022458R1

The ABB PCB CARD 3BSE022458R1 stands out as a top-rated, must-have component for industrial automation, reflecting lofty standards and noble craftsmanship. This multi-layer, OEM-quality PCB offers a robust combination of high reliability, precision manufacturing, and environmental resistance with conformal coating. At just 180 grams, it is easy to handle and install, making it a top-tier choice for ABB control systems, including AC 800M and S800 I/O platforms. With RoHS and CE certifications, this bargain solution ensures over 10 years of industrial performance and serviceability through authorized ABB centers. Plug into excellence for seamless integration with your automation infrastructure.

Versatile Usage Across Industrial Plants

The ABB PCB CARD 3BSE022458R1 is specifically designed for use in demanding industrial automation setups, seamlessly integrating with ABB DCS/PLC control systems. Its multi-layer construction and high-reliability features make it an ideal choice for manufacturing facilities, process automation plants, and critical control environments. It excels in applications requiring stable 24V DC operation and conforms to rigorous industry standards, providing noble support to processing industries seeking precision and longevity.

Swift Delivery, Flexible Terms for Cost-effective Logistics

ABB PCB CARD 3BSE022458R1 ensures efficient logistics with prompt delivery schedules, keeping your expenditure in check. Upon placing your order, typical handover time ranges from a few business days to two weeks, depending on stock and destination. Samples are available upon request to evaluate product suitability before large-scale investment. Payment terms are flexible, accommodating standard industrial arrangements to streamline your procurement and keep your operations running smoothly.

FAQs of ABB PCB CARD 3BSE022458R1:

Q: How can I ensure the ABB PCB CARD 3BSE022458R1 fits my ABB automation system?

A: Verify compatibility with ABB AC 800M, S800 I/O, or related platforms, as the card is designed specifically for plug-in integration with these control systems.

Q: What are the primary advantages of using this PCB card in a process automation setup?

A: The card offers high reliability, precision manufacturing, and environmental resistance through conformal coatingideal for robust, long-term industrial automation applications.
