ABB HBR01-FPN BASE MODULE

Get a Price/Quote

MOQ : 1 Piece

ABB HBR01-FPN BASE MODULE Specification

Rated Operation Voltage
230V AC

Features
High Impact Resistance, Flame Retardant, Easy Mounting

Control System
Manual

Thickness
2 mm

Way
Single

Rated Insulation Voltage
500V

Components
Base only, No Fittings

Connectivity Type
Terminal Block

Cooling System
Passive

Current Rating
16A

Base Material
Thermoplastic

Cover Material
Polycarbonate

Rated Current
16A

Operating Voltage
230V AC

Protection Class
Class II

Protection Level
IP20

Panel Type
Modular

Product Type
BASE MODULE

Material
High-grade Thermoplastic

Surface Finish
Matte

Standard
IEC / EN Compliant

Surface Color
White

Rated Voltage
230V AC

Frequency (MHz)
50/60 Hz

Maximum Output Current
16A

Dimension (L*W*H)
90 mm x 18 mm x 64 mm

Application
Industrial and Commercial Electrical Installations

IP Rating
IP20

Storage Temperature
-40C to +70C

Ambient Temperature Range
-25C to +55C

Terminals
Zinc Plated Steel

Flammability Rating
UL 94 V-0

Compatibility
Suitable for ABB Modular Panel Systems

Mounting Method
DIN Rail Mounting

Conductor Section
Up to 4 mm2

Weight
Approx. 100 g

About ABB HBR01-FPN BASE MODULE

Buy the ABB HBR01-FPN BASE MODULE to elevate your modular panel installations. Engineered with incomparably high-grade thermoplastic, this top-rated base module offers first-string protection at a competitive pricing point. Its extraordinary featuresflame retardancy per UL 94 V-0, IP20 protection, and high impact resistanceensure safe and reliable performance. Featuring a DIN rail mounting method, the HBR01-FPN supports conductor sections up to 4 mm, operates seamlessly from -25C to +55C, and meets IEC / EN standards. Suitable for industrial and commercial applications across India, this offering stands unmatched for durability and integrity.

Comprehensive Application & Outstanding Features

The ABB HBR01-FPN BASE MODULE excels in varied application media, catering to industrial and commercial electrical installations with ease. Its design makes it perfect for modular panel systems where reliability and safety are paramount. Notable features include a matte white finish, high impact resistance, and a flame-retardant high-grade thermoplastic body. Simple DIN rail mounting and terminal block connectivity ensure quick installation, making it an indispensable component for robust and adaptable power distribution.

Sample, Packaging & Certifications Designed for Confidence

Experience premium assurance with an available sample of the ABB HBR01-FPN BASE MODULE. Each unit is subject to meticulous quality checks and swift packing & dispatch procedures, guaranteeing quick delivery across India. Packaging protects the product integrity through transit, while all units are IEC / EN certified and compliant with UL 94 V-0 flame retardant standards, reinforcing their trustworthiness and adherence to industry benchmarks for safety and quality.

FAQs of ABB HBR01-FPN BASE MODULE:

Q: How does the ABB HBR01-FPN BASE MODULE enhance safety in electrical installations?

A: The ABB HBR01-FPN BASE MODULE is engineered with high-grade thermoplastic and rated UL 94 V-0 for flame retardancy, providing a high level of fire resistance. Its IP20 protection class prevents accidental contact with live components, ensuring superior safety in industrial and commercial applications.

Q: What are the compatibility options for the ABB HBR01-FPN BASE MODULE?

A: This module is designed for ABB Modular Panel Systems, ensuring seamless integration in new or existing panels. Its DIN rail mounting makes it compatible with standard setups, and its terminal block connectivity simplifies the installation process.

Q: When can I expect delivery after placing an order for the ABB HBR01-FPN BASE MODULE?

A: Thanks to a quick dispatch process, orders for the ABB HBR01-FPN BASE MODULE are typically packed and shipped promptly, ensuring minimal lead times to customers across India. Exact delivery timelines depend on your suppliers location and shipping preferences.

Q: Where is the ABB HBR01-FPN BASE MODULE most effectively utilized?

A: This base module is ideal for both industrial and commercial electrical installations, particularly in environments requiring robust modular panel systems with strong safety and protection credentials.

Q: What certifications and quality standards does the ABB HBR01-FPN BASE MODULE meet?

A: The module is IEC / EN compliant, carries the UL 94 V-0 flammability rating, and is manufactured with high-grade thermoplastic and polycarbonate materials to meet stringent industry safety and performance standards.

Q: How does the installation process work for this base module?

A: Installing the ABB HBR01-FPN BASE MODULE is straightforward: simply mount it on a DIN rail and connect conductors up to 4 mm via its zinc-plated steel terminal blocks. No additional fittings are needed, thanks to its manual control system and passive cooling design.
