ABB ES100F CURRENT TRANSDUCER

Get a Price/Quote

ABB ES100F CURRENT TRANSDUCER Specification

Rated Current
100 A

Operating Voltage
24 V DC (Power supply)

Way
Din Rail Mounted

Cover Material
Polycarbonate

Rated Operation Voltage
720 V

Thickness
Approx. 35 mm

Control System
Analog Output

Current Rating
100 A

Protection Level
IP20

Rated Insulation Voltage
3 kV AC

Features
Fast response, Accurate measurement, Compact design

Base Material
Plastic

Components
Hall Effect Sensor, PCB, Terminal Blocks

Cabinet Material
Plastic

Protection Class
Class II

Cooling System
Natural Air Cooling

Connectivity Type
Screw Terminal

Product Type
Current Transducer

Material
Plastic/Polycarbonate (Housing)

Surface Finish
Matte

Standard
IEC 61010-1

Surface Color
Blue and Black

Rated Voltage
720 V AC/DC

Frequency (MHz)
DC/50-60 Hz

Maximum Output Current
100 mA

Dimension (L*W*H)
70 mm x 35 mm x 75 mm

Application
Industrial Automation and Measurement

IP Rating
IP20

Ambient Temperature Range
-10C to +70C

Response Time
<5 ms

Input Current Range
0-100 A

Output Type
Analog (0-5 V or 4-20 mA depending on model)

Input-Output Isolation
Galvanic Isolation

Dielectric Strength
3 kV AC/50Hz/1min

Relative Humidity
90% (non-condensing)

Mounting Type
DIN Rail Mount

Linearity
1% of FS

Storage Temperature
-25C to +80C

Weight
Approx. 120 g

ABB ES100F CURRENT TRANSDUCER About

Experience superior current measurement with the ABB ES100F Current Transducer. Personalise your industrial automation setup with this classic device, offering precise analog output (0-5 V or 4-20 mA). Designed for a valiant performance, it handles input currents up to 100 A and features galvanic isolation for extra safety. Its fast response time (<5 ms) and accurate measurement ensure you stay ahead in efficiency. Try now at the lowest price and enjoy reliable, compact design with DIN rail mounting. Ideal for robust, critical applications.

Enhanced Performance for Industrial Applications

The ABB ES100F Current Transducer is meticulously engineered for use in demanding industrial automation and measurement contexts. Designed for easy DIN rail mounting, its robust plastic and polycarbonate housing with a blue and black matte finish fits seamlessly into control cabinets. Extra features such as galvanic isolation, rapid response, and precise analog output elevate its suitability for continuous monitoring in power distribution, control panels, and energy management systems, ensuring safety and durability in various applications.

Efficient Logistics and Global Compliance

Shipped via major FOB ports with meticulous logistics coordination, the ABB ES100F Current Transducer is ready for immediate handover to customers. This device carries key certifications, including IEC 61010-1, ensuring compliance with international safety standards. Widely available across main domestic markets, buyers benefit from reliable access and expert support, making procurement straightforward and efficient for large-scale industrial and commercial projects.

FAQs of ABB ES100F CURRENT TRANSDUCER:

Q: How do I install the ABB ES100F Current Transducer?

A: The ABB ES100F is designed for quick and secure DIN rail mounting. Connect the input and output terminals using screw connectors as specified in the product manual, ensuring correct power supply and wiring for optimal performance.

Q: What are the main benefits of using the ABB ES100F in industrial settings?

A: The device offers accurate current measurement, fast response time, galvanic input-output isolation, and robust construction. These features make it superior for automation and measurement in harsh industrial environments.

Q: When should I choose the 0-5 V versus the 4-20 mA output model?

A: Select the output type based on the compatibility of your existing monitoring equipment. The 0-5 V output is ideal for standard analog input devices, while 4-20 mA is better for long-distance signal transmission and noise resistance.

Q: Where can I use this current transducer most effectively?

A: The ABB ES100F is ideally suited for industrial automation panels, energy management systems, and other control cabinets where precise and reliable current monitoring is required.

Q: What extra features distinguish the ABB ES100F from other current transducers?

A: Key extra features include a compact, lightweight design, compliance with IEC 61010-1 standards, fast response (<5 ms), dielectric strength of 3 kV, and a broad operating temperature range. These features enhance versatility and safety.
