ABB DSDC 150 PCB TERMINAL BOARD

Get a Price/Quote

MOQ : 1 Piece

ABB DSDC 150 PCB TERMINAL BOARD Specification

Connector Type
Screw Clamp

Feature
High reliability, easy termination, vibration resistant

Shape
Rectangular

Operating Temperature
-20C to +70C

Humidity %
5% to 95% RH, non-condensing

Surface Finish
Tin-plated contact points, solder mask coating

IP Rating
IP20 (non-enclosed PCB)

Insulation Material
Polycarbonate, Epoxy Resin

Efficiency
N/A (passive component)

Mounting Type
Panel Mount / PCB Mount

Power Factor
N/A (passive component)

Product Type
TERMINAL BOARD

Application
Used for reliable electrical connections and signal transmission in ABB industrial automation systems

Protection Level
Basic insulation

Frequency (MHz)
DC to 60 Hz

Rated Voltage
250 V AC/DC

Energy Consumption
N/A (passive component)

Output Type
Screw/Clamp Terminal Output

Color
Green (PCB), Multi-color terminal blocks

Dimension (L*W*H)
Approx. 130 mm x 90 mm x 20 mm

Weight
Approx. 150 g

Phase
Single Phase / Three Phase Compatible

Size
Standard ABB control board size

Input Voltage
Up to 250 V AC/DC

Connection Type
Screw Terminal

No Of Poles
16

Material
FR4 Epoxy PCB with plated copper traces and polycarbonate connectors

About ABB DSDC 150 PCB TERMINAL BOARD

Unlock instant savings with the praiseworthy ABB DSDC 150 PCB Terminal Board, your gateway to matchless electrical performance. Preeminent in its class, this RoHS-compliant board is ideal for ABB industrial automation systems. Featuring basic insulation, UL94 V-0 flammability rating, and robust vibration resistance, it accommodates conductor sizes from 0.2 mm to 2.5 mm. The green rectangular 2-layer FR4 epoxy PCB with tin-plated contact points assures high reliability and effortless termination. Get it now for reliable signal transmissionthis deal stands out for panel and PCB mounting versatility!

Optimized for Industrial AutomationABB DSDC 150 Board

The ABB DSDC 150 PCB Terminal Board is purpose-built for reliable electrical connections and precise signal transmission in industrial automation settings. Its tin-plated surface and solder mask coating ensure low-resistance connections on panels or PCB surfaces. Ideal for ABB control boards, it offers the advantage of high reliability, vibration resistance, and easy screw terminal termination, streamlining installation across single or three-phase applications.

Certifications, Logistics, and Sample Availability for ABB DSDC 150

This terminal board is RoHS compliant and meets IPC solderability standards, reflecting ABBs commitment to quality and safety. Upon payment, products are securely packaged and handed over to trusted logistics partners, ensuring swift and safe delivery across India. Samples are available for evaluation, allowing customers to assess quality and compatibility before purchase, with flexible payment terms to support seamless transactions.

FAQs of ABB DSDC 150 PCB TERMINAL BOARD:

Q: How does the ABB DSDC 150 PCB Terminal Board support industrial automation systems?

A: The ABB DSDC 150 PCB Terminal Board delivers reliable electrical connections and signal transmission, making it an essential component in ABB industrial automation systems for both single-phase and three-phase configurations.

Q: What are the advantages of using this terminal board in control panels?

A: Its matchless insulation levels, vibration resistance, and easy screw-terminal connection enable faster installation, stable operation, and maintenance convenience in control panels across demanding industrial environments.

Q: Where can the ABB DSDC 150 PCB Terminal Board be mounted?

A: It provides flexibility for both panel mounting and PCB mounting, aligning with standard ABB control board sizes for effortless integration into your systems.

Q: What certifications does the ABB DSDC 150 PCB Terminal Board hold?

A: This product is RoHS compliant and meets IPC standards for solderability, ensuring adherence to quality, safety, and environmental regulations.

Q: How can I request a sample and what is the process for delivery?

A: Samples are available for evaluation; once requested and payment terms are agreed, the product is securely packaged and handed over to logistics partners for delivery anywhere in India.

Q: What is the benefit of the boards tin-plated contact points and solder mask coating?

A: These features enhance the boards resistance to oxidation, lower contact resistance, and increase overall longevity and reliability in industrial applications.
