ABB DRIVE ACS800-104-0610-5+E205+V991

Get a Price/Quote

ABB DRIVE ACS800-104-0610-5+E205+V991 Specification

Cooling Method
Air Cooled (Internal Fan)

Output Type
Three-phase AC

Connector Type
Screw Terminal / Busbar

Rated Current
610 A

Application
Industrial Motor Control, Pumps, Fans, Conveyors, Mixers

Power Supply
AC Mains

Current Range
0 to 610 A

Power Factor
>0.95

Working Temperature
-15C to +40C (without derating)

Noise Level
<75 dB (A)

Phase
3 Phase

Operating Temperature
-15C to +40C

Rated Power
800 kW

Output Current
610 A

Features
Direct Torque Control (DTC), Built-in EMC filter, Extensive I/O, Programmable logic

Product Type
AC Drive

Output Power
800 kW

Output Frequency
0 to 500 Hz

Input Voltage
380-500 V AC

Voltage Protection
Overvoltage and Undervoltage Protection

Efficiency
Up to 98%

Material
Industrial Grade Components / Metal Housing

Line Regulation
0.1%

Storage Temperature
-40C to +70C

Weight
Around 385 kg

Regeneration Capability
Yes (Active Supply Unit)

Standards Compliance
IEC/EN 61800-3, IEC/EN 61800-5-1, CE Certified

Programming Interface
ABB Drive Composer

Max Output Voltage
500 V AC

Cooling Fan Replacement
Yes, User Serviceable

Display
LCD Control Panel

Control Methods
Scalar, Vector, Direct Torque Control

Brake Chopper
Optional

Communication Protocols
Profibus, Modbus, DeviceNet (optional modules)

Ingress Protection
IP00

Mounting Type
Wall Mounted / Floor Standing

About ABB DRIVE ACS800-104-0610-5+E205+V991

ABB DRIVE ACS800-104-0610-5+E205+V991

ABB ACS800-104-0610-5+V991 is outdated.

Type- ACS800-104-0610

Name- ACS800-104-0610-5+V991

SKUSUQ0MYF7FH

Weight-120 Kilogrammes

Dimensions Item Identification Number- REP420020

TC Code- 68685265

Manufacted in- Finland

TYPE :ACS800-104-0610-5+E205+V991

Product ID:68685265

ABB Type Designation:ACS800-104-0610-5

Catalog Description:ACS800-104-0610-5; Inverter, R8i, 500V 610kVA+du/dt ACS800-104-0610-5+E205+V991

Country of Origin:Finland (FI)

Customs Tariff Number:85044088

Invoice Description:Inverter, R8i, 500V 610kVA+du/dt ACS800-104-0610-5+E205+V991

Made To Order:Yes

Minimum Order Quantity:1 piece

Order Multiple:1 piece

Quote Only:No

Selling Unit of Measure:piece

Dimensions

Product Net Weight:130 kg

Product Net Height:1397 mm

Product Net Length:596 mm

Product Net Width:245 mm

Additional Information

Product Main Type:ACS800-X04

Product Name:Inverter

Classifications

UNSPSC:39120000

39122001

Advanced Motor Control

Benefit from innovative control methodsscalar, vector, and ABBs Direct Torque Control (DTC)that deliver superior accuracy and responsiveness. This makes the drive optimal for applications requiring high precision such as conveyors, pumps, and mixers. With scalable output frequencies up to 500 Hz, users enjoy remarkable flexibility across varying process demands.

Easy Integration and Monitoring

The ACS800-104 is equipped with an LCD control panel and supports industrial communication protocols like Profibus and Modbus, enhancing system integration and remote monitoring. The drives compatibility with ABB Drive Composer simplifies programming and diagnostics, allowing for efficient setup, troubleshooting, and process optimization.

Robust Design and Serviceability

Built with industrial-grade metal housing and extensive protective features including overvoltage/undervoltage protection, the drive ensures reliable operation in harsh environments. User-serviceable components such as the cooling fan and optional brake chopper enable straightforward maintenance and reduce downtime, maximizing operational uptime.

FAQs of ABB DRIVE ACS800-104-0610-5+E205+V991:

Q: How do I install the ABB DRIVE ACS800-104-0610-5+E205+V991 for my facility?

A: Installation can be performed as a wall-mounted or floor-standing setup, depending on your space requirements. Ensure a suitable environment with temperature ranges between -15C to +40C, and follow ABBs guidelines for electrical connections via screw terminals or busbars. Professional installation by a qualified electrician is recommended for safety and compliance.

Q: What industrial applications are suitable for this drive?

A: The ACS800-104 is designed for industrial motor control tasks, making it well-suited for applications such as pumps, fans, conveyors, and mixers. Its high output power and flexible control methods support efficiency and precision in both light and heavy-duty operations.

Q: When should I replace the cooling fan or perform maintenance?

A: The cooling fan is user-serviceable and replacement should be based on the manufacturers maintenance schedule or if increased operational noise or overheating occurs. Periodic inspection of the fan and other user-accessible components helps ensure reliable and efficient operation.

Q: Where can communication modules be integrated for protocol support?

A: Optional modules for Profibus, DeviceNet, and other protocols can be installed in designated module slots on the drive. This feature allows seamless integration with existing factory automation systems and enables remote monitoring and control when required.

Q: What process does the ACS800-104 use to handle voltage protection?

A: The drive is equipped with overvoltage and undervoltage protection circuits. These features automatically manage abnormal voltage conditions, safeguarding the drive and connected motors from electrical stress or damage, and ensuring process continuity.

Q: How does regeneration capability benefit my application?

A: With an active supply unit, the ACS800-104 supports energy regeneration. This allows excess energy generated during braking or deceleration to be fed back to the grid, reducing overall energy consumption and improving system efficiency.

Q: What are the primary advantages of using this drive for industrial motor control?

A: Key benefits include ABBs Direct Torque Control for precise speed and torque management, built-in EMC filtering, robust programmability, and extensive I/O. Its high efficiency (up to 98%) and compliance with international safety standards further enhance operational reliability and energy savings.
