ABB 3BDH000032R1 FIELDBUS MODULE 0337318 D

Send Inquiry

Request To Call Back

ABB 3BDH000032R1 FIELDBUS MODULE 0337318 D

Get a Price/Quote

ABB 3BDH000032R1 FIELDBUS MODULE 0337318 D Specification

Power Factor
>0.95

Surface Finish
Matte

Operating Temperature
-25C to +55C

Efficiency
>98%

Mounting Type
DIN Rail

IP Rating
IP20

Connector Type
Screw Terminals

Insulation Material
Polycarbonate

Feature
High-Speed Communication, Diagnostics LED

Shape
Rectangular

Overheating Protection
YES

Humidity %
10% - 95% RH, Non-condensing

Product Type
Fieldbus Communication Module

Application
Industrial Automation, Process Control

Protection Level
Enhanced Circuit Protection

Frequency (MHz)
50/60 Hz

Rated Voltage
24V DC

Energy Consumption
Low Power

Output Type
Digital

Color
Black-Grey

Dimension (L*W*H)
104 mm x 34 mm x 58 mm

Weight
150g

Size
Standard Module

Input Voltage
24V DC

Phase
Single Phase

Connection Type
Terminal Block

No Of Poles
2

Material
Industrial Grade Plastic, Electronic Components

Housing Type
Enclosed

Model Number
3BDH000032R1

Storage Temperature
-40°C to +70°C

LED Indicators
Power, Status, Communication

Part Number
0337318 D

Response Time
<5 ms

Shock Resistance
IEC 60068-2-27

Data Rate
Up to 12 Mbps

Compliance
CE, RoHS

Protocol Supported
Fieldbus, PROFIBUS DP

About ABB 3BDH000032R1 FIELDBUS MODULE 0337318 D

ABB 3BDH000032R1 FIELDBUS MODULE 0337318 D

ABB 3BDH000032R1 FIELDBUS MODULE
ABB
3BDH000032R1
FIELDBUS M. PROFIBUS DPV1
FI 830F
DA 0602
HW 03.02
FW 04.00
0337317.J
EZW FI830F 3BDH000032R1 11164 01.06
0337318 D
CCTECH CM-1
94V-0
MADE IN GERMANY
WEIGHT: 150 GM
CONDITION : USED 1 PCS
REF NO : 26830(C)

High-Speed and Reliable Communication

The ABB 3BDH000032R1 provides exceptional communication capabilities with data rates up to 12 Mbps and response times of less than 5 ms. Designed for seamless integration into industrial networks, it supports both Fieldbus and PROFIBUS DP protocols to ensure rapid data exchange and dependable operation in process control environments.

Industrial-Grade Durability and Safety

This modules industrial-grade polycarbonate housing, along with enhanced circuit protection and compliance with CE, RoHS, and IEC 60068-2-27 standards, shields your operations from shocks, extreme temperatures, and moisture. Its robust construction makes it suitable for challenging environments, providing consistent reliability and safety.

Efficient Installation and Operation

Featuring a compact, enclosed design with DIN rail mounting and screw terminal blocks for easy wiring, the ABB module is straightforward to install. Diagnostic LED indicators streamline system monitoring, enabling quick identification of power, status, and communication issues to ensure minimal downtime and optimal performance.

FAQs of ABB 3BDH000032R1 FIELDBUS MODULE 0337318 D:

Q: How is the ABB 3BDH000032R1 FIELDBUS MODULE installed in an industrial automation setting?

A: The module is designed for DIN rail mounting and utilizes screw terminal connections, making installation within control panels simple. Ensure the device is securely attached to the DIN rail and follow wiring diagrams for terminal block connections to integrate with your network.

Q: What protocols and applications does this module support?

A: The ABB 3BDH000032R1 supports Fieldbus and PROFIBUS DP protocols, making it ideal for industrial automation and process control applications where reliable, high-speed communication is essential.

Q: When should I use the diagnostic LED indicators on this module?

A: Use the power, status, and communication LEDs to quickly check operational states during setup, troubleshooting, or routine maintenance. These indicators help you identify issues such as power faults or network communication problems right away.

Q: Where can this fieldbus module be installed, considering environmental conditions?

A: The module can be installed in environments with operating temperatures from -25C to +55C and storage temperatures from -40C to +70C. With an IP20 rating and humidity tolerance of 10% to 95% RH (non-condensing), its suitable for protected industrial areas.

Q: What process is involved in ensuring enhanced circuit protection?

A: The device incorporates advanced internal circuitry and insulation materials, aligning with IEC and RoHS standards to prevent damage from electrical surges and overheating, ensuring long-term reliable performance in industrial settings.

Q: What benefits does this module offer for industrial process control?

A: Users benefit from high-speed, stable digital communication, low power consumption, and outstanding durability. The quick response and diagnostic features contribute to higher efficiency and reduced downtime in industrial operations.

Q: How energy efficient is the ABB 3BDH000032R1 module?

A: With a power factor exceeding 0.95 and energy efficiency above 98%, the module is optimized for low power consumption, helping reduce operational costs while maintaining reliable network performance.
