ABB 1MRK002247-CGr02 PCB CARD

Get a Price/Quote

MOQ : 1 Piece

ABB 1MRK002247-CGr02 PCB CARD Specification

Humidity %
<95% (non-condensing)

Shape
Rectangular

Insulation Material
Epoxy Glass (FR4)

Connector Type
Edge Gold Fingers

Operating Temperature
0C to +70C

Feature
High Reliability, RoHS Compliant

Mounting Type
Plug-In Module / Card Slot

Surface Finish
Soldermask Green, White Silkscreen

Product Type
PCB Card

Application
ABB Relay Systems, Protection & Control

Rated Voltage
Typically 24V DC (application dependent)

Energy Consumption
Low

Output Type
Signal/Control

Color
Green

Dimension (L*W*H)
Approx. 170 x 60 x 15 mm

Weight
Approx. 120g

Size
Standard ABB PCB Size

Input Voltage
Application Specific

Connection Type
Edge Connector / Soldered Pins

Material
Fiberglass PCB, Electronic Components

PCB Layer
Multi-layer

Compatibility
Suitable for ABB Protection Relays

Standards
Meets industrial electronics quality standards

Model Number
1MRK002247-CGr02

Storage Temperature
-25°C to +85°C

Assembly Type
Through-Hole & Surface Mount

RoHS Status
Compliant

About ABB 1MRK002247-CGr02 PCB CARD

Explore the trending ABB 1MRK002247-CGr02 PCB Carda marvelously engineered solution for ABB Protection Relays. Built with impeccable quality, this affordable card features a towering multi-layer fiberglass structure, designed for both through-hole and surface mount assembly. With its RoHS compliance and high reliability, it meets stringent industrial standards. The ephemeral nature of innovation shines in its low energy consumption, robust insulation, and versatile plug-in module configuration. Suitable for signal and control output, its an essential, standard-size ABB card, offering superior electronics performance and enduring durability.

Versatile Applications and Usage

The ABB 1MRK002247-CGr02 PCB Card is used for protection and control in ABB relay systems, providing reliable performance in industrial and utility environments. Application places include substations, factories, and energy management facilities. Its standard usage type involves assembled integration in compatible ABB protection relays, using edge connectors or soldered pins for robust connectivity. This card supports both critical infrastructure and advanced automation setups, ensuring dependable signal transmission and control functions.

Export Markets and Sample Provision

This product is actively dispatched to main export markets such as Europe, Asia, and the Middle East. Sample availability is offered to verified clients; samples are handed over following approval of asking price and sample policy. Dispatching protocols adhere to swift logistics solutions, ensuring careful handling of each PCB card. Sample policies are designed to facilitate reliable evaluation by overseas buyers, supporting decision-making and strengthening global supply relationships.

FAQs of ABB 1MRK002247-CGr02 PCB CARD:

Q: How is the ABB 1MRK002247-CGr02 PCB Card installed in ABB relay systems?

A: The ABB 1MRK002247-CGr02 PCB Card can be installed using either through-hole assembly or surface mounting in compatible ABB Protection Relays. The card fits into standard ABB plug-in modules or card slots, connected via edge gold fingers or soldered pins for secure integration.

Q: What types of applications does this PCB card support?

A: This PCB card is suitable for protection and control functions in ABB relay systems. Common application places include industrial substations, factories, and advanced automation facilities, where reliable signal and control outputs are essential.

Q: When is sample provision available for international buyers?

A: Samples are handed over to overseas clients once the asking price and sample policy are approved. Trusted buyers can request samples by following the suppliers process, ensuring careful evaluation prior to large-scale orders.

Q: Where can the ABB 1MRK002247-CGr02 PCB Card be sourced in India?

A: This PCB card is distributed by authorized suppliers and traders throughout India, particularly those specializing in ABB electronic components and industrial automation products.

Q: What is the benefit of the cards RoHS compliance and energy efficiency?

A: RoHS compliance ensures that the card meets environmental safety standards, while low energy consumption reduces operational costs and supports sustainable practices in industrial applications.
