ABB 1MRK002247-CCr02 PCB CARD

Get a Price/Quote

MOQ : 1 Piece

ABB 1MRK002247-CCr02 PCB CARD Specification

Insulation Material
Epoxy Glass Fiber

Shape
Rectangular

Surface Finish
Solder Masked and Silkscreened

Efficiency
High

Humidity %
5% to 95% RH (non-condensing)

Overheating Protection
NO

Mounting Type
Panel or Chassis Mount

Operating Temperature
-20C to +70C

IP Rating
Not Applicable (for PCB)

Connector Type
Pin/Edge Connector

Feature
High Reliability, Easy Installation

Product Type
PCB Card

Application
Protection Relay Module/Replacement

Protection Level
Standard PCB

Frequency (MHz)
50/60 Hz Compatible

Rated Voltage
24V DC

Energy Consumption
Low

Output Type
Relay Output

Color
Green with Multicolor Components

Dimension (L*W*H)
14.5 cm x 3.5 cm x 1.5 cm

Weight
150g

Phase
Single Phase

Size
Standard ABB Relay PCB Size

Input Voltage
24V DC

Connection Type
Plug-in Edge Connectors

Material
High-Grade PCB Material

About ABB 1MRK002247-CCr02 PCB CARD

Order today the ABB 1MRK002247-CCr02 PCB CARDone of the most popular and customizable solutions for ABB Protection Relays. This towering, matchless, and commanding PCB features a durable 1.6 mm thickness and a carefully engineered mix of through-hole and SMD components, guaranteeing long service life. Designed for high reliability and easy installation, it meets ABB and IEC standards. Its green, rectangular design accommodates standard ABB relay module requirements, ensuring efficient, low-energy operation at 24V DC. Enjoy high-grade build, rapid compatibility, and seamless panel or chassis mounting.

Versatile Usage and Key Features of ABB 1MRK002247-CCr02 PCB Card

The ABB 1MRK002247-CCr02 PCB Card is engineered for reliability in demanding industrial environments, making it ideal for use in protection relay modules and as a replacement PCB. Suited to single-phase applications, it incorporates a blend of surface-mount and through-hole components, ensuring robust operation. Noteworthy for its easy installation and plug-in edge connectors, this PCB card also stands out for its low energy consumption, dependable relay output, and compliance with respected industry standards.

Domestic & Export Market Details, Payment, and Shipping Information

Serving both domestic and export markets, this ABB PCB card attracts significant demand from India and abroad due to its quality and versatility. Packaging is robust, ensuring the safe transport of shipped goods. Buyers can choose from flexible payment terms to suit business needs, making procurement convenient and secure. Sample units are available on request, supporting confident purchasing decisions for large orders and ensuring the cards suitability for your relay protection systems.

FAQs of ABB 1MRK002247-CCr02 PCB CARD:

Q: How is the ABB 1MRK002247-CCr02 PCB Card typically used?

A: The ABB 1MRK002247-CCr02 PCB Card is primarily employed in ABB protection relays, either as an integral module or as a replacement for maintenance and system upgrades.

Q: What are the unique features that set this PCB apart from others?

A: This card boasts through-hole and SMD mixed components, high-grade epoxy glass fiber construction, easy plug-in edge connectors, and full compliance with ABB and IEC environmental standards, ensuring reliable and efficient operation.

Q: Where can the ABB 1MRK002247-CCr02 PCB Card be installed?

A: It is designed for flexible mounting, suiting both panel and chassis installations in automation control panels or protection relay modules.

Q: Does ABB offer customizable options for this PCB card?

A: Yes, the card can be tailored to fit specific ABB relay requirements. Customers can request custom options to ensure perfect compatibility within their systems.

Q: What is the process for ordering and receiving a sample unit?

A: To obtain a sample, contact the supplier or trader in India. Upon request, samples are shipped in secure packaging. Orders can be placed for both single and bulk quantities, with flexible payment and delivery arrangements.
