ABB 10000006316 BGAD-21C FS500R17OE4DP PCB CARD

Send Inquiry

Request To Call Back

ABB 10000006316 BGAD-21C FS500R17OE4DP PCB CARD

Get a Price/Quote

ABB 10000006316 BGAD-21C FS500R17OE4DP PCB CARD Specification

IP Rating
IP00 (intended for enclosure installation only)

Connector Type
Edge and socket connectors

Feature
Factory calibrated, Original ABB component, Reliable integration

Shape
Rectangular

Surface Finish
Smooth, solder mask coating

Power Factor
N/A (signal level PCB)

Mounting Type
PCB Slot/Indoor Mount

Overheating Protection
Not applicable (passive electronic)

Humidity %
5% to 95% RH (non-condensing)

Insulation Material
FR4 PCB material

Efficiency
Not applicable (signal processing PCB)

Operating Temperature
0C to +60C (Typical)

Product Type
Drive Control PCB Card

Application
Used in ABB Drive and Power Electronics Modules

Protection Level
Conformal Coated

Frequency (MHz)
Designed for Standard Drive Frequencies

Rated Voltage
Low Voltage (As per drive specification)

Energy Consumption
Very Low / Signal Level

Output Type
Digital & Analog Signals

Color
Green with Multicolor Electronic Components

Dimension (L*W*H)
Approx. 220 mm x 140 mm x 20 mm

Weight
Approx. 250 g

Size
Standard ABB Module Card Size

Phase
Single Phase Compatible

Input Voltage
Supplied from main drive electronics

Connection Type
Plug-in edge connectors and sockets

Material
High-grade PCB (Printed Circuit Board)

Serial Number
Unique to Each Card

Lead Free
Yes (RoHS)

Storage Temperature
-25°C to +85°C

Compatibility
FS500R17OE4DP IGBT Power Modules and ABB Drives

Repairability
Field-replaceable as per ABB guidelines

PCB Layers
Multi-layer

ESD Protection
Integrated Design Standard

Packaging Type
Antistatic sealed packaging

Maintenance
No routine maintenance required except for dust cleaning

Lifecycle
Designed for long operation in industrial environments

Model Number
10000006316 BGAD-21C FS500R17OE4DP
